Compressor Characteristics | 45Revised 08/14
8 733 914 818 (2014/08)SV Heat Pump Series
COMPRESSOR CHARACTERISTICS
Model
Voltage
Code
Rated Voltage
Compressor Data Plate Cold Winding Resistance
Values (+/- 10%)
Run
Capacitor
(µF/V)
Phase RLA LRA
Single Phase Three Phase
R-C S-C Line-Line
SV007 VT & CF
1 208-230/60/1 1 2.6 17.7 4.08 6.63 - 15/370
2 265/60/1 1 2.6 13.5 5.34 6.77 - 15/440
SV007 HZ
1 208-230/60/1 1 2.6 17.7 4.08 6.63 - 15/370
2 265/60/1 1 2.6 13.5 5.34 6.77 - 15/440
SV009 VT & CF
1 208-230/60/1 1 3.4 22.2 2.95 7.35 - 15/370
2 265/60/1 1 2.9 18.8 4.27 10.74 - 10/440
SV009 HZ
1 208-230/60/1 1 3.4 22.2 2.95 7.35 - 15/370
2 265/60/1 1 2.9 18.8 4.27 10.74 - 10/440
SV012 VT & CF
1 208-230/60/1 1 4.6 28 2.3 5.9 - 20/370
2 265/60/1 1 3.8 22.2 3.47 8.7 - 15/440
SV012 HZ
1 208-230/60/1 1 4.6 27.9 2.3 5.9 - 20/370
2 265/60/1 1 3.8 22.2 3.47 8.69 - 15/440
SV015
1 208-230/60/1 1 5.6 29 2.31 5.45 - 25/440
2 265/60/1 1 4.6 20 3.58 7.39 - 15/440
SV018
1 208-230/60/1 1 6.5 43 1.431 2.383 - 30/370
2 265/60/1 1 5.8 46 1.4 2.4 - 30/440
SV024
1 208-230/60/1 1 7.4 43 1.431 2.383 - 35/370
2 265/60/1 1 6.7 46 1.4 2.4 - 30/440
3 208-230/60/3 3 5.9 63 - - 1.362 -
4 460/60/3 3 2.9 30 - - 5.329 -
SV030
1 208-230/60/1 1 9.9 54 0.982 1.729 - 35/370
2 265/60/1 1 8.5 46 1.4 2.46 - 30/440
3 208-230/60/3 3 6.9 63 - - 1.362 -
4 460/60/3 3 3.6 30 - - 5.329 -
SV036
1 208-230/60/1 1 13.0 74 0.819 1.634 - 40/370
2 265/60/1 1 11.3 67 0.802 1.76 - 35/440
3 208-230/60/3 3 7.8 68 - - 1.152 -
4 460/60/3 3 3.9 34 - - 4.606 -
SV042
1 208-230/60/1 1 13.6 88 0.656 1.558 - 45/370
3 208-230/60/3 3 8.8 68 - - 1.152 -
4 460/60/3 3 4.4 34 - - 4.606 -
SV048
1 208-230/60/1 1 15.7 84 0.54 1.6 - 45/370
3 208-230/60/3 3 11.0 88 - - 0.928 -
4 460/60/3 3 5.4 44 - - 3.593 -
SV060
1 208-230/60/1 1 26.3 134 0.453 0.792 - 80/370
3 208-230/60/3 3 15.6 110 - - 0.68 -
4 460/60/3 3 7.8 52 - - 3.2 -
SV070
1 208-230/60/1 1 28.3 178 0.97 0.365 - 80/370
3 208-230/60/3 3 19.2 136 - - 0.6 -
4 460/60/3 3 8.7 67.1 - - 2.52 -
