Bose 1401 I Series User Manual

26
Figure 5. Speaker Exploded View
SPEAKER PART LIST
Item Number Description Part Number Qty. Note
1 Plain Grille Assy, Grey
Plain Grille Assy, Black
112023
119548
1
1
2 Escutcheon (For Deluxe Grille) 1401 111769 1
3 4.5" Driver 119179 1
4
Escutcheon (For Deluxe Grille)1401 II
119511 1
5 Masonite Gasket 112410 1
6 Deluxe Grille - Reflector only 111785 1
7 Grille Assembly, (6"x 9") 123705 1
8 Frame (For Deluxe Grille) 111768 1
9 6"x 9" Driver 123456 1
10 Adapter Plate Kit 112573 1
--- Speaker Mounting Kit 119304 1
--- Speaker, Mounting Kit (6"x 9") 123644 1
--- Owner's, Manual, 1201 123696 1
--- Owner's, Manual, 1401 114733 1
---
Owner's, Manual, 1401 II
119287 1
--- LFR-069 EQ 124244 1 5
(Refer to Figure 5)
