ELECTRICAL PART LIST
Amplifier PCB Assembly
Resistors
Capacitors
Reference Designator Description Part Number Note
C101, 201 30pF, Ceramic Disc, 10%,
1000V
182779
C102, 202 470uF, AE, AXL, 20%, 6.3V 182783
C103, 203 68pF, Ceramic Disc, 10%,
1000V
182778
C104, 108, 204, 208 22uF, AE, AXL, 20%, 35V 182782
C105, 107, 205, 207 50pF, Ceramic Disc, 10%,
1000V
182777
Reference Designator Description Part Number Note
R100, 200 1k, CF, 1/4W, 5% 182788
R101, 115, 201, 215 10.0k, MF, 1/4W, 1% 182800
R102, 107, 114, 116, 202, 207, 214,
216
1.5k, MF, 1/4W, 1% 182802
R103, 117, 203, 217 4.7k, CF, 1/4W, 5% 182796
R104, 119, 204, 219 910Ω, MF, Fuse, 1/4W, 5% 182810
R105, 120, 143, 205, 220, 243 100Ω, MF, Fuse, 1/4W, 5% 182806
R106, 121, 206, 221 43Ω, MF, Fuse, 1/4W, 5% 182807
R108, 118, 208, 218 750Ω, MF, Fuse, 1/4W, 5% 182809
R109, 209 29.4k, MF, 1/4W, 1% 199754 4
R109, 209 45.3k, MF, 1/4W, 1% 182803 5
R110, R210 2.2k, CF, 1/4W, 5% 182793
R111, 112, 211, 212 909Ω, MF, 1/4W, 1% 182804
R113, 213 100k, MF, 1/4W, 1% 182801
R122, 222 16k, CF, 1/4W, 5% 182791
R123, 223 3.6k, CF, 1/4W, 5% 182794
R124, 224 Pot, Trim, PCMT, 5kΩ 182786
R125, 126, 225, 226 4.7Ω, MF, Fuse, 1/4W, 5% 182808
R127, 128, 134, 227, 228, 234 51k, CF, 1/4W, 5% 182797
R129, 229 100k, CF, 1/4W. 5% 182790
R130, 230 510k, CF, 1/4W, 5% 182798
R131, 132, 231, 232 750Ω, CF, 1/4W, 5% 182799
R133 10Ω, CF, 1/4W, 5% 182787
R136, 236 10kΩ, CF, 1/4W, 5% 182789
R138, 141, 238, 241 150Ω, CF, 1/4W, 5% 199753 4
R138, 141, 238, 241 220Ω, CF, 1/4W, 5% 182792 5
R139, 140, 239, 240 4.3k, CF, 1/2W, 5% 182795
R144, 145, 146, 147, 148, 149, 150,
151, 152, 153, 154, 155, 244, 245,
246, 247, 248, 249, 250, 251, 254, 255
0.22Ω, Metal Oxide Film,
2W
182805 5
RT100, 200 Thermistor, NTC, 1/2W,
5%, 1000Ω
182785
Reference Designator Description Part Number Note
A5 PCB Assy, Amplifier,
1600VI
199781 1, 2, 4
A5 PCB Assy, Amplifier,
1800VI
182756 1, 2, 5
To Next Page
