System Controls and Indicators
English
The media center
The media center has a control panel on the top, a display area to show the current status of
the system, and a disc tray that opens on the front of the console.
Control panel
The media center has six buttons located on the top control panel. Their functions are also
available through use of the remote control.
Figure 21
Media center controls
Note: If you selected another source by pressing the Source button, you cannot control the
new source with the remote until you press the button for that new source on the remote.
Display indicators
With the system turned on, the music center display lights up to show the state of the
system. Not all possible choices, shown below, light up at once (Figure 22). The display
changes with each adjustment or selection you make.
Figure 22
Sample media center
display
®
On-Off Source – Volume + Enter Eject
Turns system
power on or
off.
Steps through
the available
source
selections.
Lowers or raises
the volume level.
Opens or
closes the
disc tray.
•Used to navigate
through menus.
• Selects the next
available FM/AM
preset.
DVD 0:06:11
CHAPTER 1/12
SHUFFLE REPEAT DISC TRACK
Lights to indicate
shuffle mode is
selected for the
current disc.
Lights to indicate
repeat mode is
selected for cur-
rent track or disc.
Lights to indicate
“Repeat Disc” or
“Shuffle Repeat
Disc” mode is
selected.
Lights to indicate
“Repeat Track”
mode is selected.
Lights briefly when a
remote control com-
mand is received.
Lights to indicate
disc is in play.
