Bose 301 Series III Service Manual

301 Series III Parts List (Figure 3)
7
Item
Number
Description Part Number Qty.
Per
Speaker
Assy.
See Note
1 Grille Assembly-Dark Brown 143767-1 1
Grille Assembly-Black 143767-3 1
Grille Assembly-White 143767-4 1
2 Nameplate-Gold/Brown Bkgnd. 132545-04 1
Nameplate-Clear/Black Bkgnd. 132545-01 1
3 Trim Strip-Black 143770-1 1
Grille Clip (Not Illustrated) 120716 2
4 Woofer-8" or 120713 1
Woofer-8" 181870-001 Replace in pairs 10/2002
5 Screw- HIRS,8-10x3/4,PAN,XRC/SQ 137527-12 10
6 Woofer Gasket 120715 1
7 Grille Fastener 117995 6
8 Tweeter 3" 130714 2 Alt124618
9 Tweeter Mounting Bracket 128501 2
10 Screw- Machine,8-32x1/2,Hex Washer
Hd.
121441-08 2
11 Terminal Cup Connector 120711 1
12 Screw- 6-10x1/2,PAN,XRC/SQ 138897-08 4
