Model 500PM Loudspeaker (see Figure 3)
MAIN PART LIST
Item
Number
Description Part Number Qty. Note
1 INSERT, THREADED, M8 189769 2
2 SCREW, TAPP, 8-11x.75, PAN, XRC/SQ 172672-12 27
3 HARNESS, 500PM 189772 1
4 ROD, .375-16UNCx8.5” 189768 1
5 GROMMET, GRILLE SOCKET 176068 6
6 DRIVER ASSY, 4.5” 187233-001 3
7 CONN, BINDING POST, GREY 187232-003 1
8 CROSSOVER ASSY, 500PM 189781 1
9 SCREW, HILO, #6 X .375, PAN, XREC 175972-06 4
10 GASKET, WOOFER, 6.5” 104794-08 2
11 WOOFER ASSY, 5.25”, DUAL 189824-001 2
12 BEZEL, ARRAY 189766 1
13 NUT, HEX, .437-14 103236-4414 2
14 GRILLE, 500PM 189778 1
15 TAPE, FOAM 103068 4
16 SPACER, ROUND, .56IDX.44LG 189525-001 2
17 WASHER, LOCK, .456, .437, EXT T 108261-43 2
18 SCREW, HILO, 8-18, HEXW, HEX, BLK 185207-12 6
19 NAMEPLATE 122812-0 1
20 BOLT, MOUNTING, FLAT, HEX 143580 2
