Bose Companion 3 Series II Service Manual

18
Reference
Designator
Description Part Number Note
R01 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
R02 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
R03 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
R04 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
R05 2.00K, 0805, 1/10W, 1% 133625-2001
R06 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
R07 412 OHMS, 0805, 1/10W, 1% 133625-4120
R08 JUMPER, CHIP, 0805 133627
R09 412 OHMS, 0805, 1/10W, 1% 133625-4120
R10 JUMPER, CHIP, 0805 133627
R11 10.0 OHM, 0805, 1/10W, 1% 133625-10R0
RT1 22K, THERMISTOR, RADIAL, 1/4W, 5% 177557
3
RT2 22K, THERMISTOR, RADIAL, 1/4W, 5% 177557
3
VR1 VARISTOR, MET OX, 275V, 140JOULE,
US
273545-001
3
VR1 VARISTOR, MET OX, 300V, 140JOULE,
EURO
273545-002
3
VR1 VARISTOR, MET OX, 175V, 140JOULE,
JAPAN
273545-003
3
Reference
Designator
Description Part Number Note
C1 1.0uF, BOX, 85, 100V, 5% 137127-105
C2 .22uF, 0805, X7R, 25V, 10% 181264-224
C3 .047uF, 0805, X7R, 50V, 10% 133623-473
C4 .1uF, 0805, X7R, 10%, 25V 181264-104
C5 .1uF, 0805, X7R, 10%, 25V 181264-104
C7 .033F, EL, AL, 25V, 4T, US 260693-3331E
C7 .039F, EL, AL, 25V, 20% EURO 260693-3931E
C7 .039F, EL, AL, 25V, 20%, JAPAN 260693-3931E
C8 .22uF, FILM, X2, 275VAC, 15MM 268166-224B
Reference
Designator
Description Part Number Note
L1 CHOKE, COMMON MODE, WITH HEADER 277667-001
ELECTRICAL PARTS LIST
Power Supply PCB Assembly
Resistors
Capacitors
Inductors
