Bose ControlSpace ESP-88 User Manual

96
13. Viewing the test results.
The log data that was obtained by the ATS2 macro must be evaluated by opening the Excel
sheet that was described in section “4-10. Pass/Fail evaluation and report of this test.”
When this sheet shows that the unit has passed test, it can be returned to the customer.
If the test is failed, retest or repair the ESP.
Print out the results of the Excel sheet and place it with the unit to be shipped back to the
customer. The passed Excel test sheet and text (.txt) log file should be archived so that there is
a record of the unit passing test.
TEST PROCEDURES
Device under test According to OT1-400338
Serial Number ESP-1
Lot
Date of test 2005,03,13
Tester's Name
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
AMPL 4.17 4.02 3.94 4.11 3.92 3.94 4.00 3.95
Nois -80.03 -80.13 -80.05 -80.04 -81.30 -81.23 -81.30 -81.32
FRQ20K
3.39 3.08 3.05 3.15 2.87 2.98 2.74 3.04
FRQ20 3.66 3.50 3.41 3.61 3.44 3.47 3.54 3.48
THDN 0 0067 0 0068 0 0076 0 0075 0 0068 0 0068 0 0067 0 0067
Result
Passed
5-1.(GV=0dB)
Device under test According to OT1-400338-1
Serial Number
Lot
Date of test
Tester's Name
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
AMPL
Nois
FRQ20K
FRQ20
THDN
Result
FAIL
5-1.(GV=0dB)
