English • 17Owner's Guide • L1 Pro8/Pro16 Portable Line Array System
PRO.BOSE.COM
Care & Maintenance
Problem What to do
Paired Bluetooth®
device will not connect
to the loudspeaker
• If your paired device requires a passcode, make sure the one you entered is
correct.
• Make sure Bluetooth® functionality is turned on or enabled on your source
device.
• Your Bluetooth device may be out of range; try moving it closer to the L1Pro.
• If possible, turn o all other nearby Bluetooth devices or disable their
Bluetooth functionality.
• Clear the loudspeaker memory or pair to a new device by pressing and
holding the Bluetooth Pair Button for ten seconds. Delete the L1 Pro from the
Bluetooth device's memory. Pair the Bluetooth device with the L1Pro again.
• Turn the power o and back on; then try re-pairing your device.
Excessive hum when
daisy-chaining multiple
units
• Ensure the volume on the daisy-chained unit(s) is not set too high.

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
