Bose PORTABLE HOME SPEAKER User Manual

SPEAKER STATUS
39
|
ENG
UPDATE AND ERROR STATUS
Shows the status of the software updates and error alerts.
LIGHT RING ACTIVITY
SYSTEM STATE
Solid amber on top
and bottom
Wi-Fi setup in progress
White light fills
the ring counter-
clockwise until full,
then repeats
Downloading update
White light fills
the ring clockwise
until full, then
repeats
Updating speaker
Blinks amber on
the top and bottom
four times
Error - refer to the
Bose Music app
Solid red on the top
and bottom
Error - contact Bose
customer service

Bose PORTABLE HOME SPEAKER Specifications

General

Wi-Fi	Yes
3.5 mm connector	-
Connectivity technology	Wired & Wireless
Cables included	AC
Quantity per pack	1 pc(s)
Product color	Black
Volume control	Touch
Protection features	Water resistant
Battery type	Built-in battery
Power source type	Battery
Battery life (max)	12 h
Recommended usage	Tablet / Smartphone
RMS rated power	- W

Weight and Dimensions

Depth	104 mm
Width	119 mm
Height	191 mm
Weight	1060 g
