9
REMOTE CONTROL
SPECIFICATION
GENERAL
Power Supply Requirements : DC 12 Volts, Negative Ground
Tone Controls
- Bass (at 100 Hz) : ±10 dB
- Treble (at 10 kHz) : ±10 dB
Maximum Output Power : 4X50 watts
USB/SD/MMC PLAYER
Signal to Noise Ratio : More than 60 dB
Channel Separation : More than 50 dB
Frequency Response : 20Hz – 20 kHz
RADIO
FM
μ
AM
Sensitivity (S/N=20dB)
32 dBu
Remarks:
Specifications subject to change without notice.
1. VOL+: Volume Up Button
2.
(MUTE): Power On/Off/MUTE Button
3. SELECT: Sound Mode Select Button
4. TUNE/SKIP
: Tune/Seek Down Button
5. DISP: Display Button
6. VOL-: Volume Down Button
7. 1 PAU: Pause Button
8. 1-6: Preset Buttons
9. 4 SHF: Shuffle Button
10. AS/PS/D-AUD:
Automatic Memory Storing & Program Scanning
Button (Press to select th
e track directly in
MP3/WMA file Operation)
11. MODE: Mode Button
12. TUNE/SKIP
: Tune/Seek Up Button
13. BAND/LOU/ENT:
Band Select Button (When pressed shortly)
Loudness Button (When pressed and hold)
(Enter Button For MP3/WMA file Operation)
14. 2 SCN: Scanning Button
15. 3 RPT: Repeat Button
16. 6 DIR
: Directory Up Button
17. 5 DIR
: Directory Down Button
Current Consumption : 5 Ampere (max.)
Frequency Coverage
87.5 to 107.9 MHz(USA)
IF 10.7 MHz
Sensitivity (S/N=30dB)
10 dB
Stereo Separation
>25dB
Frequency Coverage 530 to 1710 kHz(USA)
IF 450 kHz
87.5 to 108 MHz(Europe/Asia)
522 to 1620 kHz(Europe/Asia)
