9
Features and Controls
Read the Operator’s Manual and safety rules before operating your electric pressure washer.
Compare the illustrations with your electric pressure washer to familiarize yourself with the locations of various
controls and adjustments. Save this original manual for future reference.
A - Spray Gun — Controls the application of water onto
cleaning surface with trigger device. Includes trigger lock.
B - Detergent Tank — Use to hold up to 40 oz. (1.2 l) of
pressure washer safe detergent.
C -Warning Label — Identifies hazards to be avoided
when using your pressure washer.
D - Spray Wand — Allows you to switch between different
spray tips.
E - High Pressure Outlet — Connection for high pressure
hose.
F - Electric Cord with GFCI — The electric pressure
washer and operator is protected by a ground fault
circuit interrupter (GFCI).
G - Water Supply Inlet — Connect to water supply using a
50 ft. (15.24 m) maximum garden hose.
H - Identification Label — Provides model and serial
number of pressure washer. Please have these readily
available if calling for assistance.
J - Master ON/OFF Toggle Switch — Push top of switch
in (I) to turn pressure washer ON. Push bottom of switch
in (0) to turn pressure washer OFF.
K - Spray Tips — Black spray tip for general soap
applications. Yellow spray tip is for various high
pressure applications.
L - Turbo Spray Tip — Whirls a powerful pin-point jet of
water for intense cleaning.
M - High Pressure Hose — Connect red end to high
pressure water outlet and black end to spray gun.
B
A
K
M
J
L
E
G
H
C
D
F
