8 BRIGGSandSTRATTON.COM
High Altitude
At altitudes over 5,000 feet (1524 meters), a minimum
85 octane / 85 AKI (89 RON) gasoline is acceptable. To
remain emissions compliant, high altitude adjustment is
required. Operation without this adjustment will cause
decreased performance, increased fuel consumption, and
increased emissions. See an Authorized Briggs & Stratton
dealer for high altitude adjustment information. Operation of
the engine at altitudes below 2,500 feet (762 meters) with
the high altitude kit is not recommended.
Attach Suction Hose
Attach Suction Hose to Pump
Use a 1-1/2” commercially available hose with threaded ends.
The suction hose must be reinforced with a non-collapsible
wall or braided material. DO NOT use a hose with an inside
diameter smaller than the pumps suction port size.
1. Screw suction hose onto pump in clockwise rotation
until suction hose is tightened securely.
Attach Suction Hose to Strainer Basket
You will need the following tools to install the suction hose
to the strainer basket:
• 1/4" or 6mm standard screwdriver
• Utility knife
IMPORTANT: Using a utility knife, cut off one threaded end of
suction hose to attach strainer basket.
Slide hose clamp over cut off end of suction hose. Attach
open end of suction hose to strainer hose barb. Tighten hose
clamp securely using a standard 1/4” (6mm) screwdriver.
Attach Discharge Hose
Use a commercially available hose with threaded ends. DO
NOT use a hose with an inside diameter smaller than the
pump’s discharge port size.The pump has two 1” and two
1-1/2” diameter discharge ports.
1. Screw discharge hose onto pump in clockwise rotation
until discharge hose is tightened securely.
IMPORTANT: Be sure all unused discharge ports are capped
and tightened securely.
