Brother MFC-5890CN Quick Setup Guide

10
10
Set your station ID
You should store your name and fax number to be
printed on all fax pages that you send.
a Press Menu.
b Press a or b to choose Initial Setup .
Press OK.
c Press a or b to choose Station ID .
Press OK.
d Enter your fax number (up to 20 digits) on the
dial pad, and then press OK.
e Enter your name (up to 20 characters) using
the dial pad, and then press OK.
f Press Stop/Exit.
Note
• See the following chart for entering your name.
• If you need to enter a character that is on the
same key as the last character, press c to
move the cursor to the right.
• If you entered a letter incorrectly and want to
change it, press d or c to move the cursor to the
incorrect character, press Clear/Back.
Press
key
One
time
Two
times
Three
times
Four
times
2 ABC2
3 DEF 3
4 GH I 4
5 JKL5
6 MNO6
7 PQRS
8 TUV8
9 WX Y Z
Note
If you make a mistake and want to start again,
press Stop/Exit and go back to a.
For details, see Entering Text in Appendix C
of the User's Guide.
Note
(USA only)
The Telephone Consumer Protection Act of 1991
makes it unlawful for any person to use a
computer or electronic device to send any
message via a telephone fax machine unless
such messages clearly contain, in a margin at the
top or bottom of each transmitted page, or on the
first page of the transmission, the date and time it
is sent and an identification of the business or
other entity or other individual sending the
message and the telephone number of the
sending machines or such business, other entity
or individual.

Brother MFC-5890CN Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	28 ppm
Scan to	E-mail, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Scan speed (black)	3.44 ppm
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
PC free copying	Yes
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	80
Total input capacity	150 sheets
Total output capacity	50 sheets
Processor family	RISC
Compatible memory cards	CF, Memory Stick (MS), miniSD, MS PRO, MS Pro, SD, SDHC, xD
Sound pressure level (printing)	50 dB
Display	LCD
Display diagonal	3.3 \
Market positioning	Home & office
Maximum print size	297 x 432 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
JIS B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Dimensions (WxDxH)	485 x 408 x 242 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input frequency	50 - 60 Hz
Power consumption (standby)	6 W
Power consumption (PowerSave)	4.5 W
Power consumption (average operating)	27 W
Maximum duty cycle	- pages per month
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
