Specifications
175
D
Print media D
1
For labels, we recommend removing printed pages from the output paper tray immediately after they exit the machine
to avoid the possibility of smudging.
Model MFC-8510DN MFC-8710DW MFC-8910DW
Paper Input Paper Tray
(Standard)
Paper Type Plain Paper, Thin Paper, Recycled Paper
Paper Size Letter, A4, B5 (ISO/JIS), A5, A5 (Long Edge), B6 (ISO),
A6, Executive, Legal, Folio
Paper Weight
16 to 28 lb (60 to 105 g/m
2
)
Maximum
Paper
Capacity
Up to 250 sheets of 20 lb (80 g/m
2
) Plain paper
Multi-
purpose tray
(MP tray)
Paper Type Plain Paper, Thin Paper, Thick Paper, Thicker Paper,
Recycled Paper, Bond Paper, Label, Envelope, Env.Thin,
Env.Thick
Paper Size Width: 3 to 8.5 in (76.2 to 215.9 mm)
Length: 5 to 14 in (127.0 to 355.6 mm)
Paper Weight
16 to 43 lb (60 to 163 g/m
2
)
Maximum
Paper
Capacity
Up to 50 sheets of 20 lb (80 g/m
2
) Plain paper
Paper Tray 2
(Optional)
Paper Type - Plain Paper, Thin Paper, Recycled
Paper
Paper Size - Letter, A4, B5 (ISO/JIS), A5, B6 (ISO),
Executive, Legal, Folio
Paper Weight -
16 to 28 lb (60 to 105 g/m
2
)
Maximum
Paper
Capacity
-
Up to 500 sheets of 20 lb (80 g/m
2
)
Plain paper
Paper
Output
1
Face-Down Output Tray
Up to 150 sheets of 20 lb (80 g/m
2
) Plain Paper (face-down
delivery to the face-down output paper tray)
Face-Up Output Tray One sheet (face-up delivery to the face-up output tray)
Duplex Automatic
Duplex
Printing
Paper Type Plain Paper, Thin Paper, Recycled Paper
Paper Size Letter, Legal, Folio
Paper Weight
16 to 28 lb (60 to 105 g/m
2
)
