Brother MFC-8510DN Service Manual

5-41
Confidential
1.3.26 Display machine log information (function code: 80)
<Function>
This function is used to display the log information on the LCD.
<Operation Procedure>
(1) Press the [8] and [0] buttons in this order in the initial state of maintenance mode.
"USB:********" is displayed on the LCD.
(The machine serial number is displayed for *********.)
(2) Pressing the [Start] or [ ] button displays the next item.
Pressing the [ ] button returns to the previous item.
(3) When the [Stop/Exit] button is pressed, the machine returns to the initial state of
maintenance mode.
Display information
LCD *
1
Description
USB:000G8J000166 Serial number
MAC:008077112233 *
2
MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87% Estimated remaining toner amount detected by toner sensor
KTN_RRM:67% Estimated remaining toner amount based on the rotations of
developer roller
DRUM_PG:00000000 Printed pages for drum
PFMP_PG:00000000 Pages fed from MP paper feeding kit
PFK1_PG:00000000 Pages fed from paper feeding kit 1
PFK2_PG:00000000 Pages fed from paper feeding kit 2
FUSR_PG:00000000 Printed pages for fuser unit
LASR_PG:00000000 Printed pages for laser unit
TTL_PG:00000000 Total printed pages
TTLCOPY:00000000 Total pages copied
TTLPCPT:00000000 Total pages printed via PC
TTLFAX:00000000 Total pages faxed
KCVRGUSI:4.32% Average coverage by the toner cartridge which is currently used
KCVRGACC:3.47% Accumulated average coverage
DRUM:00000000 Rotations of the drum
KTN_RND:00000000 Rotations of the developer roller
MP_PG:00000000 Pages printed from MP tray
TR1_PG:00000000 Pages printed from paper tray 1
DX_PG:00000000 Duplex printed pages
TR2_PG:00000000 Pages printed from paper tray 2
A4+LTR:00000000 Printed pages of A4 size and Letter size paper
LG+FOL:00000000 Printed pages of Legal size and Folio size paper
B5+EXE:00000000 Printed pages of B5 size and EXE size paper

Brother MFC-8510DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
PictBridge	No
Scan speed	2.68 sec/page
Dimensions (WxDxH)	405 x 415 x 423 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	500 - 3500 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	36 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ICA, ISIS, TWAIN
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Image formats supported	BMP, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	300
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	1
Maximum number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	LCD
Market positioning	Home & office
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	Ethernet, USB 2.0
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, EAP-TTLS, MD5, PEAP
Internal memory	64 MB
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	1.2 W
Power consumption (standby)	8.1 W
Power consumption (PowerSave)	336 W
Power consumption (average operating)	651 W
Package weight	20.100 g
Sustainability certificates	ENERGY STAR
