Brother MFC-8880DN Service Manual

3-24
Confidential
■ Error code 84
Paper jam in the back cover
■ Error code 85
Tray 1 is not installed into the machine
Error code 86
Tray 2 is not installed into the machine
Jam Rear
Open the Back Cover and remove the jammed paper, then press Start.
<User Check>
• Check if the paper is jammed around the opened back cover. If jammed, remove it.
Step Cause Remedy
1
Harness connection failure of relay
rear PCB ASSY.
Check the harness connection of the relay
rear PCB ASSY and reconnect it.
2
Eject actuator catching on some
position
Correct catching of the eject actuator.
3
Paper eject sensor PCB failure Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the relay rear PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
No Tray
A Tray is not detected, install Tray 1.
No Tray
A Tray is not detected, install Tray 2.
<User Check>
• Check if the applicable tray is installed into the machine.
• Check if the paper is jammed in the applicable tray.
Step Cause Remedy
1
T1 PE/edge sensor PCB/
T2 PE/edge sensor PCB failure
Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the T1 PE/edge sensor PCB failure/T2 PE/
edge sensor PCB.
2
Harness connection failure of
T1 PE/edge sensor PCB/
T2 PE/edge sensor PCB.
Check the harness connection of the T1
PE/edge sensor PCB/T2 PE/edge sensor
PCB. and reconnect it.
3 Main PCB failure Replace the main PCB ASSY.
4
Connector 55533-1219 failure
(only Tray 2)
Replace the connector 55533-1219.

Brother MFC-8880DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16
Time to first copy (black, normal)	10.5 s
Copy speed (black, normal quality, A4)	30 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	64 MB
Card reader integrated	No
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Display	LCD
Market positioning	Business
Dimensions (WxDxH)	531 x 451 x 475 mm
All-in-one functions	Copy, Fax, Print, Scan
Maximum internal memory	0.576 GB
Color all-in-one functions	Scan
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	85 W
Power consumption (PowerSave)	18 W
Power consumption (average operating)	680 W
Maximum duty cycle	- pages per month
Package weight	22100 g
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
