Chapter 2
22
Paper settings 2
Paper Size and Type 2
To get the best print quality, set the machine
for the type of paper you are using.
You can use eight sizes of paper for printing
copies: Letter, Legal, Ledger, A4, A5, A3,
Executive and 4  6in. (10 15 cm) and five
sizes for printing faxes: Ledger, Letter, Legal,
A3 or A4. When you load a different size of
paper in the machine, you will need to change
the paper size setting at the same time so
your machine can fit an incoming fax on the
page.
a Press Tray Setting.
b Press the displayed paper size or paper
type for Tray#1, or press the displayed
paper size for Tray#2.
c Do one of the following:
 If you chose the paper size for
Tray#1, press d or c to display the
paper size options, and press
Letter, Legal, Ledger, A4, A5,
A3, EXE or 4"x6".
 If you chose the paper type for
Tray#1, press Plain Paper,
Inkjet Paper, Brother BP71,
Brother BP61, Other Glossy
or Transparency.
 If you chose Tray#2, press Letter,
Legal, Ledger, A4, A3 or EXE.
d Press Stop/Exit.
Note
• You can only use plain paper in Tray#2.
• The machine ejects paper with the printed
surface face up onto the paper tray in the
front of the machine. When you use
transparencies or glossy paper, remove
each sheet at once to prevent smudging
or paper jams.
Tray use in COPY mode 2
You can change the default tray the machine
will use for copies.
Auto Select will allow your machine to
feed paper from either Tray #1 or Tray #2,
using the paper type and size settings from
the COPY key menu.
To change the default setting, follow the
instructions below:
a Press Tray Setting.
b Press a or b on the Touchscreen to
display Tray Use:Copy.
c Press Tray Use:Copy.
d Press Tray#1, Tray#2 or
Auto Select.
e Press Stop/Exit.
Note
You can temporarily change the paper
size and tray selection for the next copy by
using the COPY mode key. (See Paper
Size on page 55 and Tray Select
on page 56.)

Brother MFC-J6510DW Specifications

General

Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Scan to	E-mail, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	A3 (297 x 420) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	2400 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	50 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	35 sheets
Processor family	RISC
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC
Sound pressure level (printing)	50 dB
Display	LCD
Product color	Black
Display diagonal	3.3 \
Market positioning	Business
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 431.8 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	5x7, 5x8 \
Borderless printing media sizes	5x7, A3, A4, A6, Index card, Letter
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Mobile printing technologies	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Scan speed	3.49 sec/page
Dimensions (WxDxH)	540 x 489 x 257 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.5 W
Power consumption (PowerSave)	4 W
Power consumption (average operating)	26 W
Sustainability certificates	ENERGY STAR
Package weight	22.400 g
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	489 mm
Width	540 mm
Height	257 mm
