Brother MFC-J6530DW Service Manual

Confidential
2-92
4.10.7 Noise comes from machine
4.10.8 “Unusable Device” is displayed
< User Check >
- Disconnect the unsupported USB device.
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 Foreign materials around the
maintenance unit
Remove foreign materials.
3 CR encoder strip stained Clean the CR encoder strip.
4 PF encoder disk stained Clean the PF encoder disk.
5 Looseness of the CR timing
belt
Re-hook the CR timing belt properly.
6 Looseness of the switchback
roller belt
Re-hook the switchback roller belt properly.
7 Looseness of the paper feed
roller belt
Re-hook the paper feed roller belt properly.
8 Looseness of the paper
ejection roller belt
Re-hook the paper ejection roller belt properly.
9 Looseness of the 3rd tray
paper feed belt
Re-hook the 3rd tray paper feed belt properly.
10 Looseness of the CIS drive
belt
Re-hook the CIS drive belt properly.
11 Paper feed motor not mounted
in place
Set the paper feed motor into place.
12 Carriage motor not mounted in
place
Set the carriage motor into place.
13 3rd tray paper feed motor not
mounted in place
Set the 3rd tray paper feed motor into place.
14 CR encoder strip defective Replace the CR encoder strip.
15 PF encoder disk defective Replace the PF encoder disk.
16 Maintenance unit defective Replace the maintenance unit.
17 ADF unit defective Replace the ADF unit.
18 Document scanner unit
defective
Replace the document scanner unit.
Step Cause Solution
1 Main PCB defective Replace the main PCB.

Brother MFC-J6530DW Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono	22 ipm
Print speed (ISO/IEC 24734) color	20 ipm
Time to first page (black, normal)	6 s
Duplex print speed (ISO/IEC 24734) mono	12 ipm
Duplex print speed (ISO/IEC 24734) color	11 ipm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Duplex copying	No
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	12 cpm
Copy speed (color, normal quality, A4)	9 cpm
Scan to	E-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan drivers	ICA, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Scan speed (black)	8 inch/min
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (color)	18 ppm
Optical scanning resolution	1200 x 2400 DPI
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	100
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	2.67 \
Market positioning	Business
Photo paper sizes	9x13, 10x15, 13x18 cm
Custom media width	105 - 297 mm
Custom media length	148 - 431.8 mm
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes, Photo paper, Recycled paper
Paper tray media weight	64 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO C-series sizes (C0...C9)	C5
Photo paper sizes (imperial)	13x18 \
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Internal memory	128 MB
Sound power level (standby)	50 dB
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security features	APOP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, FTPS, SMTP, POP3, IMAP4), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS resolver, mDNS, LLMNR responder, LPR/LPD, custom Raw Port/Port9100, IPP, FTP/FTPs client FTP server, SNMPv1/v2c/v3, TFTP server, SMTP client, ICMP, web services (Print/Scan), CIFS client, SNTP client, POP3, LDAP, IMAP4, HTTP server
Supported network protocols (IPv6)	NDP, RA, mDNS, LLMNR responder, DNS resolver, LPR/LPD, custom raw port/Port9100, IPP, FTP/FTPs client FTP , SNMPv1/v2c/v3 , TFTP server, web services (print/scan), SMTP client, POP3*, CIFS client, SNTP client, LDAP, IMAP4*, ICMPv6, HTTP serve
Package depth	568 mm
Package width	681 mm
Package height	430 mm
Package weight	23900 g
Sustainability certificates	Blue Angel, ENERGY STAR
Power consumption (off)	0.4 W
Power consumption (sleep)	1.6 W
Power consumption (standby)	6 W
Power consumption (average operating)	27 W
Cartridge type	LC3217
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Page description languages	-
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Android
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic
Bundled software	Brother Control Center Version 4, Nuance PaperPort Version 14
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	305 mm
