USING ATTACHMENTS AND APPLICATIONS
UTILISATION DES ACCESSOIRES ET LEURS APPLICATIONS
USO DE ACCESORIOS Y APLICACIONES
OPTIONAL
ACCESSORIES
Using the Walking Foot
Pattern Stitch Length Stitch Width
(Straight Stitch)
1-4
2-3
(Zigzag Stitch) 0-5
This foot is very useful for sewing materials such as vinyl cloth,
synthetic leather, thin leather, etc. These materials are difficult to
feed when sewing. The walking foot prevents such materials from
crumpling, slipping or sticking between presser foot and material
due to even feeding of upper and lower materials.
NOTE:
Use foot only for straight sewing and zigzag stitching. Do not use
other patterns.
1. Remove the power supply plug from the outlet.
2. Raise the needle and the presser foot.
3. Loosen the presser foot screw to remove the presser foot holder.
(See fig. A)
4. Attach the forked section of the connecting lever to the needle
clamp, install the walking foot to the presser bar. (See fig B)
5. Lower the presser foot lever and then tighten the accessory
presser bar holder fixing screw. (See fig.C)
1 Forked part of operation lever
2 Presser bar holder
1 Use a screwdriver
CAUTION
• Use the screwdriver to tighten the screw securely. If the
screw is loose, the needle may strike the presser foot
and cause injury.
• Be sure to turn the balance wheel toward the front of the
machine to check that the needle does not strike the
presser foot. If the needle strikes the presser foot, injury
may result.
• Be careful not to touch the needle during this time,
otherwise injury may result.
CAUTION
When sewing with the walking foot, sew at medium to low
speeds.
1
2
C
B
A
To Next Page
