9BSST FIVE CHANNEL POWER AMPLIFIER
9
Typical Band-pass Noise
Typical THD+N Harmonic Content
Power supply artifacts are all below -95 dBu
balanced input with 23dB gain shown
The harmonic content of the 9BSST is all even order.
dBu: dB relative to a reference of 0.7746 Volts
Typical Frequency Response
8 ohm 120w<.01dB 20Khz.
4 ohm 200w<.1dB 20Khz.
Typical Phase Response
4 ohm 200w
8 ohm 120w
