3. assembling the seat
The seat comprises the seat fabric, which is pulled over the frame. The seat
fabric is fitted with back pad supports, foot support and seat pad. The seat has
2 shoulder belts, 1 crotch belt and 1 tensioning belt with metal O-rings. The seat
fabric has cut-aways on the left and right for the waist belts. The frame has 2
waist belts. When fastened together, the waist belts should stay in place at the
height of the side supports.
step 1 placing the seat fabric on the frame
a. Fold out the frame supports and place the frame
on the floor.
b Slide the rounded upper side of the base seat fabric
over the round side of the frame, with the Bugaboo logo
facing forward. Pull on the seat fabric so that it fits tightly.
c Place one O-ring of the tensioning belt over the
protruding pin on the side of the frame.
d. Place the frame on that side to fasten the O-ring on
the other side.
e. Lean on the frame and push it inwards a little. Take
hold of the tensioning belt and pull the other metal
O-ring over the protruding pin.
f Attach the ends of the stretch belt underneath the seat.
You should hear a click.

Bugaboo Cameleon Specifications

General

Type	Traditional stroller
Foldable	Yes
Washing type	Machine wash
Product color	Aluminium, Khaki
Frame material	Aluminum
Number of seats	1 seat(s)
Wheels material	Foam
Maximum baby weight	17 kg
Recommended age (max)	36 month(s)
Recommended age (min)	6 month(s)
Number of front wheels	2
Stroller accessories included	Rain cover
Wheels mobility	Fixed, Swivel

Weight and Dimensions

Weight	9600 g
Folded depth	900 mm
Folded width	500 mm
Folded height	310 mm
