Fuses Usage
DR/LCK
TRUNK
Door Locks, Trunk
HAZRD Turn Signal, Hazard
HTD/MIR Heated Mirrors
HTD/SEAT Heated Seats
HVAC Climate Control System
INT/ILLUM Interior Lamps
ONSTAR/ALDL OnStar
®
, Data Link
PRK/LAMP Park Lamps
PRK/SWTCH Ignition Key Lock
PWR/MIR Power Mirrors
PWR/SEAT Power Seats
PWR/WNDW Power Window
RDO/AMP Radio, Amplifier
Fuses Usage
RFA/MOD Remote Keyless Entry
S/ROOF Sunroof
STR/WHL/
ILLUM
Steering Wheel Controls Illumination
Relays Usage
RAP Retained Accessory Power
PRK/LAMP Park Lamp Relay
R/DEFOG Rear Defogger Relay
Underhood Fuse Block
Some fuses and relays are located in the underhood
fuse block on the passenger side of the vehicle in
the engine compartment. See Engine Compartment
Overview on page 5-12 for more information on location.
Notice: Spilling liquid on any electrical components
on the vehicle may damage it. Always keep the
covers on any electrical component.
