10-24 Vehicle Care
Headlamps, Front Turn
Signal and Parking
Lamps
Driver Side Shown, Passenger
Side Similar
1. Turn Signal Lamp
2. Low-Beam Headlamp
3. Parking Lamp
4. High-Beam Headlamp
High-Beam Headlamp/
Low-Beam Headlamp
1. Open the hood. See Hood on
page 10-4.
2. Remove the headlamp bulb
access cover.
3. Turn the bulb counterclockwise
and pull straight back.
4. Disconnect the wiring harness
connector from the bulb.
5. Install the new bulb in the
headlamp assembly by turning
clockwise.
6. Reconnect the wiring harness
connector.
7. Install the headlamp bulb access
cover.
