2.6.2 P&ID "Piping and Instrumentation Diagram"
M
PSA+
0301
0201
LS-
PS+
0301
TSA+
0104
TSA+
0101
TS+
0101
M
PSA+
0301
0201
LS-
PS+
0301
TSA+
0104
TSA+
0101
TS+
0101
IF
M
IF
Optional
Optional
or
or
P&ID for classification B , C and E
P&ID for classification A
P&ID for classification D
Optional
Optional
or
or
3 Transport
WARNING
Suspended load.
Risk of severe injury!
• Do not walk, stand or work under suspended loads.
WARNING
Lifting the machine using the motor eye bolt.
Risk of severe injury!
• Do not lift the machine using the eye bolt fitted to the motor. Only lift the machine as
shown.
NOTICE
In case the machine is already filled with oil.
Tilting a machine that is already filled with oil can cause large quantities of oil to in-
gress into the cylinder. Starting the machine with excessive quantities of oil in the
cylinder will immediately break the vanes and ruin the machine!
• Drain the oil prior to every transport or always horizontally transport the machine.
• Make sure that the eyebolt(s) (EB) is/are in faultless condition, fully screwed in and
tightened by hand.
