CAME G3000 User Manual

p.
2
2 - Manual code:
FA00028-EN
FA00028-EN v.
1
- 05/2015 - © Came S.p.A. The data and information in this manual may be changed at any time and without notice.
Danger of hand crushing
Danger! High voltage.
No transiting while the barrier is moving
WARNING!
important safety instructions for people:
READ CAREFULLY!
Premise
• This product should only be used for the purpose for which it was explicitly
designed. Any other use is dangerous.CAME S.p.A. is not liable for any damage
caused by improper, wrongful and unreasonable use. • The safety of this product
and its proper fi tting depends, therefore, on respecting its technical characteristics
and proper fi tting, to be done in state-of-the-art fashion, and under safe conditions
as expressly explained in the literature that comes with the product. • Keep these
warnings together with the installation and operation manuals that come with the
operator.
Before installing
(checking what's there: if something is missing, do not continue until you
have complied with all safety provisions)
• Fitting and testing must be only performed by qualifi ed technicians • Laying
the cables, installation and testing must follow state-of-the-art procedures as
dictated by standing regulations • Before beginning any operation it is mandatory
to carefully read all instructions; improper installation may result in serious harm
to people and things • Make sure the boom is in good mechanical state, balanced
and aligned, and that it opens and closes properly. Also, if needed, fi t suitable
protections or use proper safety sensors • If the operator is to be installed at a
height of less than 2.5 m from the ground or other access level, make sure you
have any necessary protections and/or warnings in place • Make sure that the
opening automatic barrier does not constitute a hazard • Do not fi t upside down
or onto elements that could bend. If necessary, add suitable reinforcements to
the anchoring points • Check that the temperature range shown on the operator
is suitable for the climate where it is installed. • Do not install on tilted surfaces
or slopes • Make sure any sprinkler systems cannot wet the operator from the
ground up.
Installing
• Suitably section o and demarcate the entire installation site to prevent
unauthorized persons from entering the area, especially minors and children •
Be careful when handling operators that weigh over 20 kg. If need be, use proper
safety hoisting equipment • The CE-marked safety devices (photocells, stepping
plates, sensitive safety-edges, emergency buttons, and so on), must be fi tted
in compliance with the regulations in e ect and according to state-of-the-art
criteria, taking into account the environment, the type of required service and of
the working forces applied to moving barriers. Any shearing or conveying points
must be sensor-protected • Any residual risks must be clearly indicated • All
opening commands (that is, buttons, key switches, magnetic readers, and so on)
must be installed at least 1.85 m from the perimeter of the barrier's working
area, or where they cannot be reached from outside the barrier. Also, any direct
commands (buttons, touch panels, and so on) must be installed at least 1.5
m from the ground and must not be reachable by unauthorized persons • The
automatic barrier must visibly show its identifi cation data • Before connecting
the main power supply make sure that the identifi cation data correspond to the
those of the network • The automatic barrier must be connected to an e ective
regulation grounding system.
• The manufacturer declines any liability for using non-original products; which
would result in warranty loss • All maintained action commands, must be fi tted in
places from which the moving barrier and transit and driving areas are visible •
Apply, if missing, a permanent sign showing the position of the release device •
Before delivering to the users, make sure the system is EN 12453 and EN 12445
standard compliant (regarding impact forces), and also make sure the system has
been properly adjusted and that any safety, protection and manual release devices
are working properly • Apply Warning Signs where necessary and in a visible
place, (such as, the gate's license plate)
Special user-instructions and recommendations
• Keep barrier operation areas clean and free of any obstructions. Make sure the
photocell's operating fi eld is clear of any obstructions • Do not allow children to
play with fi xed commands, or to loiter in the barrier's maneuvering area. Keep any
remote control transmitters or any other command device away from children,
to prevent the operator from being accidentally activated • The apparatus may
be used by children of eight years and above and by physically, mentally and
sensory-challenged people, or even ones without any experience, provided this
happens under close supervision or once they have been properly instructed to
use the apparatus safely and to the potential hazards involved. Children must not
play with the apparatus. Cleaning and maintenance by users must not be done
by children, unless properly supervised • Frequently check the system for any
malfunctions or signs of wear and tear or damage to the moving structures, to
the component parts, all anchoring points, including cables and any accessible
connections. Keep any hinges, joints and friction points properly lubricated and
clean of debris. • Perform functional checks on the photocells every six months.
Constantly clean the photocells' glass covers using a slightly water-moistened
cloth; do not use solvents or chemicals that could damage the devices • If repairs
or modifi cations are required to the system, release the operator and do not use it
until safety conditions have been restored • Cut o the mains power supply before
releasing the operator for manual openings. Read the instructions If the power
supply cable is damaged, it must be replaced by the manufacturer or authorized
technical assistance service, or in any case, by similarly qualifi ed persons, to
prevent any risk • It is FORBIDDEN for users to perform any OPERATIONS THAT
ARE NOT EXPRESSLY REQUIRED OF THEM AND WHICH ARE NOT LISTED in the
manuals. For any repairs, modifi cations and adjustments and for extra-ordinary
maintenance, CALL TECHNICAL ASSISTANCE • Log the job and checks into the
periodic maintenance log.
Further recommendations for all
• Keep away from and do not loiter near the barrier and mechanical moving parts
• Do not enter the barrier's area of operation when it is moving • Do not counter
the operator's movement as this could result in dangerous situations • Always pay
special attention to any dangerous points, which have to be labeled with specifi c
pictograms and/or black and yellow stripes • When using a selector switch or a
command in maintained actions, keep checking that there are no persons within
the operating range of any moving parts, until the command is released • The
barrier may move at any time and without warning • Always cut o the power
supply before performing any maintenance or cleaning.
