CAME ZA4 User Manual

-2-
GENERAL CHARACTERISTICS
C aution! Disconnect the unit from
the main power lines before carrying
out any operation inside the unit.
ENGLISH
Description of control board
The ZA4 control board is suitable for
controlling automation of ATI, FERNI
and FROG series 230V swing gates
with up to 600W power and 50-60Hz
frequency.
Wholly designed and built by CAME
S.p.A., it meets UNI 8612 regulations
in force. The board is inserted and
fixed to the ABS case (S4339 o
S4340), which has an IP54 protection
level, with air recycling inlet and
transformer.
The board requires 230V (a.c.) at
terminal blocks L1-L2 and the inlet is
protected with two 5A fuses. A 1A fuse
protects the low voltage command
devices.
The accessories’ total wattage (24V)
must not exceed 20W.
Safety
Photocells can be connected to obtain:
- Re-opening during closure (2-C1), if
the photocells identify an obstacle
while the gate is closing, they will
reverse the direction of movement until
the gate is completely open;
- Total stop (1-2), shutdown of gate
movement without automatic closing; a
pushbutton or radio remote control
must be actuated to resume
movement).
Accessories which can be
connected to this unit
- Flashing signal light when gate is in
motion 25W max. (E1-W):
- Radiofrequency «AF» board (see
table pag.7).
Other functions available
- Automatic closing. The automatic
closing timer is automatically activated
at the end of the opening cycle. The
preset, adjustable automatic closing
time is automatically interrupted by the
activation of any safety system, and is
deactivated after a STOP command or
in case of power failure;
- "Operator present" function: Gate
operates only when the pushbutton is
held down (the radio remote control
system is deactivated);
Adjustments
- Trimmer TL = Adjustment of operating
time;
- Trimmer TR2M = Delay on closing
cycle - motor 2;
- Trimmer TCA = Adjustment of
automatic closing;

CAME ZA4 Specifications

General

Brand	CAME
Model	ZA4
Category	Control Unit
Language	English
