The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
Pag.
10 - Manual code:
319LR31 ver.
1.0 02/2009 © CAME cancelli automatici s.p.a.
ENGLISH
Trimmer SLOW.SENS. = Adjusts the amperometric sensitivity that controls the force of the engine developed during
different slow-down phases; if said force becomes greater than the adjusted level, the system intervenes by inver-
ting the direction of movement.
Trimmer A.C.T. = Adjusts the waiting time in the opening position. Once this time frame has lapsed, an automatic
closing procedure is performed. The waiting time may be adjusted to between 1 second and 120 seconds. Adjusting
to the minimum excludes the automatic closing function.
Trimmer CL.SENS. = Adjusts the amperometric sensitivity that controls the force of the engine developed during movement closing; if
said force becomes greater than the adjusted level, the system intervenes by inverting the direction of movement.
Trimmer OP.SENS. = Adjusts the amperometric sensitivity that controls the force of the engine developed during movement opening; if
said force becomes greater than the adjusted level, the system intervenes by inverting the direction of movement.
Adjustments
Function selection
1 ON - Activates the procedure for adjusting the opening and closing endpoints and the procedure for programming the decelerated
opening.
2 ON - Activates the procedure for adjusting the partial opening and the procedure for programming the decelerated endpoint closing.
