Canon EOS 600D User Manual

B: Matching the Light SourceN
118
2
Select [Custom White Balance].
Under the [2] tab, select [Custom
White Balance], then press <0>.
X The custom white balance selection
screen will appear.
3
Import the white balance data.
Select the image that was captured in
step 1, then press <0>.
X On the dialog screen which appears,
select [OK] and the data will be
imported.
When the menu reappears, press the
<M> button to exit the menu.
4
Select the custom white balance.
Press the < WB > button.
Select [O], then press <0>.
If the exposure obtained in step 1 is way off, a correct white balance
might not be obtained.
An image captured while the Picture Style was set to [Monochrome]
(p.82) or an image processed with a Creative filter cannot be selected in
step 3.
Instead of a white object, an 18% gray card (commercially available) can
produce a more accurate white balance.
The personal white balance registered with EOS Utility (provided
software, p.302) will be registered under <O>. If you do step 3, the data
for the registered personal white balance will be erased.
www.devicemanuals.eu
0
www.devicemanuals.eu
0
On the dialog screen which appears,
www.devicemanuals.eu
On the dialog screen which appears,
] and the data will be
www.devicemanuals.eu
] and the data will be
When the menu reappears, press the
www.devicemanuals.eu
When the menu reappears, press the
M
www.devicemanuals.eu
M
> button to exit the menu.
www.devicemanuals.eu
> button to exit the menu.
Select the custom white balance.
www.devicemanuals.eu
Select the custom white balance.
Press the <
www.devicemanuals.eu
Press the <
www.devicemanuals.eu
Select [
www.devicemanuals.eu
Select [
www.devicemanuals.eu
www.devicemanuals.eu
www.devicemanuals.eu

Canon EOS 600D Specifications

General

Megapixel	18 MP
Camera type	SLR Camera Kit
Sensor type	CMOS
Image stabilizer	No
Total megapixels	18.7 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3456 pixels
Still image resolution(s)	480 x 480, 640 x 480, 720 x 400, 720 x 480, 1280 x 1280, 1696 x 1280, 1728 x 1728, 1920 x 1080, 1920 x 1280, 2304 x 1728, 2304 x 2304, 2592 x 1456, 2592 x 1728, 3072 x 2304, 3456 x 1944, 3456 x 2304, 3456 x 3456, 4608 x 3456, 5184 x 2912, 5184 x 3456
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Canon EF, Canon EF-S
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	9
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Manual, Red-eye reduction
Flash sync-speed	1/200 s
Flash recharging time	3 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/2, 1/3 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	50 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.85 x
USB version	2.0
Material	Polycarbonate, Stainless steel
Product color	Black
Scene modes	Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)
Photo effects	Black&White, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show
Image processor	DIGIC 4
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Playback zoom (max)	10 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional
Battery type	LP-E8
Battery life (CIPA standard)	400 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Bundled software	ZoomBrowser EX\\r ImageBrowser

Weight and Dimensions

Depth	79.7 mm
Width	133.1 mm
Height	99.5 mm
Weight (including battery)	570 g
