Canon EOS 600D User Manual

255
3 Custom Function SettingsN
C.Fn III: Autofocus/Drive
C.Fn-7 AF-assist beam firing
The AF-assist beam can be emitted by the camera’s built-in flash or by an
external, EOS-dedicated Speedlite.
0: Enable
If necessary, the AF-assist beam will be emitted by the built-in flash or
external Speedlite.
1: Disable
The AF-assist beam is not emitted.
2: Enable external flash only
If an external Speedlite is attached, it will emit the AF-assist beam when
necessary. The camera’s built-in flash will not fire the AF-assist beam.
3: IR AF assist beam only
Among external Speedlites, only those which have an infrared AF-assist
beam will be able to emit the beam. This prevents any Speedlite which
uses a series of small flashes (like the built-in flash) from firing the AF-
assist beam.
With an EX-series Speedlite equipped with a LED light, the LED light will
not automatically turn on for AF-assist.
C.Fn-8 Mirror lockup
0: Disable
1: Enable
Prevents mechanical vibrations in the camera caused by the reflex
mirror action which can disturb shooting with super telephoto lenses or
close-up (macro) shooting. See page 122 for the mirror lockup
procedure.
If the external Speedlite’s [AF-assist beam firing] Custom Function is set
to [Disabled], the Speedlite will not emit the AF-assist beam even if the
camera’s C.Fn-7 is set to 0, 2, or 3.
www.devicemanuals.eu
www.devicemanuals.eu
If an external Speedlite is attached, it will emit the AF-assist beam when
www.devicemanuals.eu
If an external Speedlite is attached, it will emit the AF-assist beam when
necessary. The camera’s built-in flash will not fire the AF-assist beam.
www.devicemanuals.eu
necessary. The camera’s built-in flash will not fire the AF-assist beam.
Among external Speedlites, only those which have an infrared AF-assist
www.devicemanuals.eu
Among external Speedlites, only those which have an infrared AF-assist
beam will be able to emit the beam. This prevents any Speedlite which
www.devicemanuals.eu
beam will be able to emit the beam. This prevents any Speedlite which
uses a series of small flashes (like the built-in flash) from firing the AF-
www.devicemanuals.eu
uses a series of small flashes (like the built-in flash) from firing the AF-
With an EX-series Speedlite equipped with a LED light, the LED light will
www.devicemanuals.eu
With an EX-series Speedlite equipped with a LED light, the LED light will
not automatically turn on for AF-assist.
www.devicemanuals.eu
not automatically turn on for AF-assist.
www.devicemanuals.eu
C.Fn-8 Mirror lockup
www.devicemanuals.eu
C.Fn-8 Mirror lockup
www.devicemanuals.eu
If the external Speedlite’s [
www.devicemanuals.eu
If the external Speedlite’s [
AF-assist beam firing
www.devicemanuals.eu
AF-assist beam firing
], the Speedlite will not emit the AF-assist beam even if the
www.devicemanuals.eu
], the Speedlite will not emit the AF-assist beam even if the
camera’s C.Fn-7 is set to 0, 2, or 3.
www.devicemanuals.eu
camera’s C.Fn-7 is set to 0, 2, or 3.

Canon EOS 600D Specifications

General

Megapixel	18 MP
Camera type	SLR Camera Kit
Sensor type	CMOS
Image stabilizer	No
Total megapixels	18.7 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3456 pixels
Still image resolution(s)	480 x 480, 640 x 480, 720 x 400, 720 x 480, 1280 x 1280, 1696 x 1280, 1728 x 1728, 1920 x 1080, 1920 x 1280, 2304 x 1728, 2304 x 2304, 2592 x 1456, 2592 x 1728, 3072 x 2304, 3456 x 1944, 3456 x 2304, 3456 x 3456, 4608 x 3456, 5184 x 2912, 5184 x 3456
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Canon EF, Canon EF-S
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	9
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Manual, Red-eye reduction
Flash sync-speed	1/200 s
Flash recharging time	3 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/2, 1/3 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	50 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.85 x
USB version	2.0
Material	Polycarbonate, Stainless steel
Product color	Black
Scene modes	Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)
Photo effects	Black&White, Neutral
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show
Image processor	DIGIC 4
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Playback zoom (max)	10 x
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional
Battery type	LP-E8
Battery life (CIPA standard)	400 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Bundled software	ZoomBrowser EX\\r ImageBrowser

Weight and Dimensions

Depth	79.7 mm
Width	133.1 mm
Height	99.5 mm
Weight (including battery)	570 g
