Canon PowerShot SX510 HS User Manual

Canon PowerShot SX510 HS
168 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #121 background imageLoading...
Page #121 background image
121
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Formatting Memory Cards
Before using a new memory card or a card formatted in another device, you
should format the card with this camera.
Formatting erases all data on a memory card. Before formatting, copy
images on the memory card to a computer, or take other steps to back them
up.
1 Access the [Format] screen.
Choose [Format], and then press the
<m> button.
2 Choose [OK].
Press the <o><p> buttons to choose
[Cancel], choose [OK] (either press the
<q><r> buttons or turn the <5> dial),
and then press the <m> button.
3 Format the memory card.
To begin the formatting process, press
the <o><p> buttons or turn the <5>
dial to choose [OK], and then press the
<m> button.
When formatting is nished, [Memory
card formatting complete] is displayed.
Press the <m> button.
• Formatting or erasing data on a memory card only changes le
management information on the card and does not erase the data
completely. When transferring or disposing of memory cards, take
steps to protect personal information if necessary, as by physically
destroying cards.
• The total card capacity indicated on the formatting screen may be less than
the advertised capacity.
Low-Level Formatting
Perform low-level formatting in these cases: [Memory card error] is
displayed, the camera is not working correctly, card image reading/writing is
slower, continuous shooting is slower, or movie recording suddenly stops.
Low-level formatting erases all data on a memory card. Before low-level
formatting, copy images on the memory card to a computer, or take other
steps to back them up.
On the screen in step 1 of “Formatting
Memory Cards” (=
121), press the
<o><p> buttons or turn the <5> dial
to choose [Low Level Format], and then
press the <q><r> buttons to select this
option. A [
] icon is displayed.
Follow steps 2 – 3 in “Formatting Memory
Cards” (=
121) to continue with the
formatting process.
• Low-level formatting takes longer than “Formatting Memory Cards” (=
121),
because data is erased from all storage regions of the memory card.
• You can cancel low-level formatting in progress by choosing [Stop]. In this
case, all data will be erased, but the memory card can be used normally.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon PowerShot SX510 HS and is the answer not in the manual?

Canon PowerShot SX510 HS Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeBridge camera
Sensor typeCMOS
Image stabilizerYes
Image sensor size1/2.3 \
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)4000 x 3000, 2816 x 2112, 1600 x 1200, 640 x 480, 4000 x 2248, 2816 x 1584, 1920 x 1080, 640 x 360, 4000 x 2664, 2816 x 1880, 1600 x 1064, 640 x 424, 2992 x 2992, 2112 x 2112, 1200 x 1200, 480 x 480
Digital zoom4 x
Optical zoom30 x
Combined zoom120 x
Focal length range4.3 - 129 mm
Maximum aperture number5.8
Minimum aperture number3.4
Lens structure (elements/groups)13/10
Maximum focal length (35mm film equiv)720 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, Auto
Light exposure modesAperture priority AE, Auto, Shutter priority AE
ISO sensitivity (max)3200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/2EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed15 s
Flash modesAuto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash range (tele)0.5 - 3 m
Flash range (wide)0.5 - 5 m
Power source typeBattery
Video resolutions320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate30 fps
Video formats supportedMOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Built-in microphone-
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)461000 pixels
USB version2.0
USB connectorMini-USB B
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesFireworks, Portrait, Snow
Photo effectsBlack&White, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Shooting modesAperture priority, Auto, Manual, Movie, Shutter priority
Image processorDIGIC 4
Self-timer delay2, 10 s
Playback zoom (max)10 x
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery typeNB-6LH
Battery life (CIPA standard)250 shots
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Bundled softwareImageBrowser EX, PhotoStitch, Map Utility
Weight and Dimensions IconWeight and Dimensions
Depth69.5 mm
Width104 mm
Height80.2 mm
Weight349 g
