CONNECTION WITH A (SMART) SPEAKER
WIRELESS
In wireless mode, wireless smart loudspeakers and Smart Sub 12 are connected
via a high-end radio link. A frequency of 5.8 GHz guarantees robust and loss-free
data transmission. Once the Smart Sub 12 has been successfully connected to the
wireless loudspeaker, the Smart Sub 12 is activated and the wireless connection is
established automatically. The input selector switch at the Smart Sub 12 must be
set to WIRELESS [POWER AUTO] (factory setting). If the wireless loudspeaker is
switched off, the Smart Sub 12 also switches off automatically and the LED on the
baffle of the Smart Sub 12 lights up red. During operation (wireless as well as wired)
the LED shines green.
SMART WIRED
When using a Smart Soundbar or a Smart Sounddeck, you have the option of cont-
rolling the Smart Sub 12 wirelessly (on/standby, volume, etc.) but still supplying the
audio signal via signal cable. To do this, you must connect the Smart Sub 12 to the
Soundbar / Sounddeck as described below, then set the connection type there from
wireless to wired and finally set the input selector switch on the Smart Sub 12 from
WIRELESS [POWER AUTO] to WIRED [POWER AUTO].
WIRED
The input SUB IN is used if the Smart Sub 12 is connected via cable. The input
selector switch of the subwoofer must now be set to „WIRED [POWER ON]“ if the
Smart Sub 12 is always to remain switched on, or to „WIRED [POWER AUTO]“ if it
is to switch on resp. (delayed) off with the loudspeaker.
