6
06DR109 2.0 8.7 -40 0 -10 55 -35 0 2 2.00 1-3/8 3.00 160
06DM808 3.0 8.0 0 50 – – 0 55 2 2.00 1-1/4 3.00 160
06DR013 3.0 13.1 -40 0 -10 55 -35 0 4 2.00 1 4.50 230
06DM313 5.0 13.1 0 50 – – 0 55 4 2.00 1 4.50 235
06DR316 5.0 15.9 -40 25 -10 55 -35 25 4 2.00 1-1/4 4.50 235
06DM316 5.0 15.9 0 25 – – 0 45 4 2.00 1-1/4 4.50 235
06DR718 5.0 18.3 -40 0 -10 55 -35 0 4 2.00 1-7/16 5.50 250
06DA818 6.5 18.3 0 50 – – 0 55 4 2.00 1-7/16 5.50 250
06DR820 6.5 20.0 -40 40 -10 55 -35 45 4 2.00 1-9/16 5.50 260 06DR724 6.5 23.9 -40 25 -10 55 -35 45 6 2.00 1-1/4 8.00 310 06DR725 6.5 23.9 -40 25 -10 55 -35 45 6 2.00 1-1/4 8.00 310
06DA825 7.5 23.9 0 50 – – 0 55 6 2.00 1-1/4 8.00 315 06DA824 7.5 23.9 0 50 – – 0 55 6 2.00 1-1/4 8.00 310
06DR228 7.5 28.0 -40 25 -10 55 -35 45 6 2.00 1-15/32 8.00 315
06DA328 10.0 28.0 0 50 – – 0 55 6 2.00 1-15/32 8.00 315
06DR337 10.0 37.1 -40 25 -10 55 -35 45 6 2.00 1-15/16 8.00 325
06DM337 10.0 37.1 0 25 – – 0 45 6 2.00 1-15/16 8.00 325
06DA537 15.0 37.1 0 50 – – 0 55 6 2.00 1-15/16 8.00 325
06DR541 15.0 41.0 -40 25 -10 55 -35 25 6 2.00 2.15 8.00 325
06ER450 15.0 50.3 -40 0 – – -35 0 4 2-11/16 2-3/16 14.00 430
06EM450 15.0 50.3 0 25 -10 55 0 45 4 2-11/16 2-3/16 14.00 430
06EA550 20.0 50.3 0 50 – – 0 50 4 2-11/16 2-3/16 14.00 430
06ER465 20.0 68.3 -40 0 – – -35 0 6 2-11/16 1-63/64 19.00 480
06EA565 25.0 68.3 0 50 -10 55 0 50 6 2-11/16 1-63/64 19.00 485
06ER475 20.0 75.4 -40 0 – – -35 0 6 2-11/16 2-3/16 19.00 490
06EM475 25.0 75.4 0 40 -10 55 0 45 6 2-11/16 2-3/16 19.00 490
06EA575 30.0 75.4 0 50 – – 0 50 6 2-11/16 2-3/16 19.00 490
06ER399 30.0 99.0 -40 0 – – -35 0 6 2-11/16 2-7/8 19.00 500
06EM499 35.0 99.0 0 40 -10 55 0 45 6 2-11/16 2-7/8 19.00 505
06EA599 40.0 99.0 0 50 – – 0 50 6 2-11/16 2-7/8 19.00 520
MODEL
NUMBER
HP
R-502, 404A/507 R-12, R-134a R-22
MIN MAX MIN MAX MIN MAX
SUCTION TEMPERATURE RANGE (DEGREES F)
NUMBER OF
CYLINDERS
NET
WEIGHT
(LBS)
CFM
@1750
RPM
OIL
CHARGE
(PINTS)
STROKE
(INCHES)
BORE
(INCHES)
06D/E Compressor Specifications (60 Hz Units)
Notes: 1. The cylinder head cooling fan section of this application guide details where this accessory is required. 2. The compressor performance tables reflect the operational envelope limitations for each model by refrigerant.
Bowman Refrigeration 206-706-3033
