17
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
voltage,
Serie
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
48---30, 50,
60
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,800 2.48 8.0 58MVB080---20
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.24 29,600 2.48 8.1 58MVB100---20
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,600 2.48 8.1 58MVB120---20
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.24 29,600 2.50 8.1 58CV(A,X)090---16
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.26 29,600 2.50 8.1 58CV(A,X)110---20
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,400 2.52 8.2 58CV(A,X)135---22
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,400 2.54 8.2 58CV(A,X)155---22
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.20 31,200 2.94 8.5 58MVB080---20
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.22 31,200 2.96 8.6 58MVB100---20
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.22 31,000 2.96 8.6 58MVB120---20
CSRH*4812A* * 45,000 TDR&TXV 13.00 10.80 47,500 3.22 31,000 2.96 8.6 58CV(A,X)090---16
CSRH*4812A* * 44,500 TDR&TXV 13.20 11.00 47,500 3.24 31,000 2.98 8.6 58CV(A,X)110---20
CSRH*4812A* * 44,500 TDR&TXV 13.20 11.00 47,500 3.26 31,000 3.00 8.7 58CV(A,X)135---22
CSRH*4812A* * 45,000 TDR&TXV 13.50 11.20 47,500 3.30 30,800 3.02 8.7 58CV(A,X)155---22
CSRH*6012A* * 45,500 TDR&TXV 13.20 11.00 48,000 3.26 29,800 2.48 8.1 58MVB080---20
CSRH*6012A* * 46,000 TDR&TXV 13.20 11.00 48,000 3.28 29,600 2.50 8.2 58MVB100---20
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.26 29,600 2.50 8.1 58MVB120---20
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,600 2.50 8.2 58CV(A,X)090---16
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,600 2.52 8.2 58CV(A,X)110---20
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.32 29,400 2.54 8.3 58CV(A,X)135---22
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.34 29,400 2.54 8.3 58CV(A,X)155---22
60---30, 50,
60
*FC4DN(F,B)060 59,500 TDR&TXV 13.00 10.80 58,500 3.46 37,200 2.50 7.9
FK4DNB006 58,500 TDR&TXV 13.20 11.00 59,500 3.34 38,000 2.40 7.7
CAR**6024A** 57,500 TDR&TXV 13.00 10.80 58,500 3.38 36,600 2.46 7.7 58CV(A,X)135---22
CAR**6024A** 58,000 TDR&TXV 13.00 10.80 58,500 3.40 36,400 2.48 7.8 58CV(A,X)155---22
CNRV*6024A** 57,500 TDR&TXV 13.00 10.80 59,000 3.36 36,400 2.46 7.7 58CV(A,X)155---22
CNRH*6024A** 57,500 TDR&TXV 13.00 10.80 59,000 3.36 36,400 2.46 7.7 58CV(A,X)155---22
CSRH*6012A* * 57,500 TDR&TXV 13.00 10.80 59,000 3.42 36,400 2.48 7.8 58CV(A,X)135---22
CSRH*6012A* * 58,000 TDR&TXV 13.00 10.80 59,000 3.46 36,400 2.48 7.8 58CV(A,X)155---22
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard: 80_F(27_C) db 67_F(19_C) wb indoor entering air temperature and 95_F(35_C) db air entering outdoor unit.
High---Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 47_F(8_C) db 43˚F(6_C) wb air entering outdoor unit.
Low---Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 17_F(±9_C) db 15˚F(±10_C) wb air entering outdoor unit.
SEER — Seasonal Energy Efficiency Ratio
COP — Coefficient of Performance
TDR — Time---Delay Relay
HSPF — Heating Seasonal Performance Factor
EER — Energy Efficiency Ratio
25HBR3

Carrier 25HBR3 Specifications

Electrical Requirements

nominal unit electrical characteristics (single phase)	v, single phase, 60 hz
nominal unit electrical characteristics (three phase)	v, three phase, 60 hz
control circuit voltage	24v

Fan Specifications

condenser fan type	direct-drive propeller type
condenser fan motor type	totally enclosed, 1-phase type
fan blade balance	statically and dynamically balanced
