19
DETAILED COOLING CAPACITIES -- CONTINUED
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
25HBR324A Outdoor Section With FA4CNC024 Indoor Section
700
72 26.55 13.79 1.69 25.58 13.41 1.88 24.57 13.03 2.08 23.52 12.63 2.31 22.41 12.22 2.57 21.24 11.79 2.84
67 24.11 17.20 1.67 23.20 16.81 1.86 22.26 16.42 2.07 21.27 16.00 2.30 20.24 15.57 2.55 19.15 15.12 2.82
63 22.37 16.59 1.66 21.51 16.20 1.85 20.61 15.80 2.06 19.67 15.37 2.28 18.69 14.93 2.53 17.65 14.47 2.80
62 22.00 20.58 1.66 21.18 20.15 1.85 20.32 19.70 2.05 19.44 19.21 2.28 18.57 18.57 2.53 17.73 17.73 2.80
57 21.50 21.50 1.66 20.82 20.82 1.85 20.11 20.11 2.05 19.36 19.36 2.28 18.57 18.57 2.53 17.73 17.73 2.80
800
72 27.00 14.44 1.73 25.99 14.06 1.91 24.95 13.67 2.12 23.86 13.27 2.35 22.71 12.85 2.61 21.51 12.42 2.88
67 24.52 18.28 1.71 23.58 17.89 1.90 22.60 17.49 2.11 21.58 17.07 2.34 20.51 16.62 2.59 19.40 16.16 2.86
63 22.75 17.61 1.70 21.86 17.21 1.89 20.93 16.80 2.10 19.97 16.36 2.32 18.95 15.91 2.57 17.89 15.44 2.84
62 22.48 21.96 1.70 21.64 21.50 1.89 20.83 20.83 2.09 20.04 20.04 2.32 19.21 19.21 2.57 18.34 18.34 2.84
57 22.30 22.30 1.70 21.59 21.59 1.89 20.83 20.83 2.09 20.05 20.05 2.32 19.21 19.21 2.57 18.34 18.34 2.84
900
72 27.33 15.05 1.77 26.29 14.68 1.95 25.22 14.29 2.16 24.10 13.88 2.39 22.93 13.46 2.65 21.69 13.02 2.92
67 24.82 19.32 1.75 23.85 18.92 1.94 22.85 18.51 2.15 21.81 18.07 2.37 20.72 17.62 2.62 19.58 17.15 2.90
63 23.03 18.57 1.74 22.12 18.16 1.93 21.17 17.74 2.13 20.18 17.30 2.36 19.15 16.84 2.61 18.07 16.35 2.88
62 22.97 22.97 1.74 22.22 22.22 1.93 21.43 21.43 2.14 20.61 20.61 2.37 19.74 19.74 2.62 18.83 18.83 2.89
57 22.97 22.97 1.74 22.22 22.22 1.93 21.44 21.44 2.14 20.61 20.61 2.37 19.75 19.75 2.62 18.83 18.83 2.89
Cooling Indoor Model Capacity Power Furnace Model
*FA4CN(F,C)024 1.00 1.00
FA4CN(F,C)030 1.01 1.01
FC4DNF024 1.02 0.96
FC4DNF030 1.03 0.96
FF1ENE030 1.00 1.00
FK4DNF001 1.02 0.94
FK4DNF002 1.03 0.95
FK4DNF003 1.03 0.95
CAR**2414A** 1.01 1.01
CAR**2417A** 1.01 1.01
CAR**3014A** 1.01 1.01
CAR**3017A** 1.01 1.01
CNRF*2418A** 1.01 1.01
CNRH*2417A** 1.01 1.01
CNRH*3017A** 1.01 1.01
CNRV*2414A** 1.01 1.01
CNRV*2417A** 1.01 1.01
CNRV*3014A** 1.01 1.01
CNRV*3017A** 1.01 1.01
CSRH*2412A** 1.01 1.01
CSRH*3012A** 1.01 1.01
CAR**2414A** 1.01 0.95 58CV(A,X)070 ---12
CAR**3014A** 1.01 0.95 58CV(A,X)070 ---12
CNRH*2417A** 1.00 0.94 58CV(A,X)070---12
CNRH*3017A** 1.01 0.93 58CV(A,X)070---12
CNRV*2414A** 1.00 0.94 58CV(A,X)070---12
CNRV*3014A** 1.01 0.95 58CV(A,X)070---12
CSRH*2412A** 1.01 0.95 58CV(A,X)070---12
CSRH*3012A** 1.01 0.93 58CV(A,X)070---12
CAR**2417A** 1.01 0.93 58CV(A,X)090 ---16
CAR**3017A** 1.02 0.94 58CV(A,X)090 ---16
CNRH*2417A** 1.01 0.95 58CV(A,X)090---16
CNRH*3017A** 1.02 0.94 58CV(A,X)090---16
CNRV*2417A** 1.01 0.95 58CV(A,X)090---16
CNRV*3017A** 1.02 0.94 58CV(A,X)090---16
CSRH*2412A** 1.01 0.93 58CV(A,X)090---16
CSRH*3012A** 1.01 0.93 58CV(A,X)090---16
Cooling Indoor Model Capacity Power Furnace Model
CNRH*2417A** 1.01 0.95 58CV(A,X)110---20
CNRH*3017A** 1.02 0.94 58CV(A,X)110---20
CSRH*2412A** 1.01 0.95 58CV(A,X)110---20
CSRH*3012A** 1.01 0.93 58CV(A,X)110---20
CNRH*2417A** 1.01 0.95 58CV(A,X)135---22
CNRH*3017A** 1.02 0.94 58CV(A,X)135---22
CSRH*2412A** 1.01 0.95 58CV(A,X)135---22
CSRH*3012A** 1.01 0.93 58CV(A,X)135---22
CNRH*2417A** 1.01 0.95 58CV(A,X)155---22
CNRH*3017A** 1.02 0.94 58CV(A,X)155---22
CSRH*2412A** 1.01 0.93 58CV(A,X)155---22
CSRH*3012A** 1.01 0.93 58CV(A,X)155---22
CNRH*2417A** 1.01 0.95 58MVB040---14
CNRH*3017A** 1.01 0.93 58MVB040---14
CSRH*2412A** 1.01 0.95 58MVB040---14
CSRH*3012A** 1.01 0.93 58MVB040---14
CAR**2417A** 1.01 0.95 58MVB060---14
CAR**3017A** 1.01 0.93 58MVB060---14
CNRH*2417A** 1.01 0.95 58MVB060---14
CNRH*3017A** 1.01 0.93 58MVB060---14
CNRV*2417A** 1.01 0.95 58MVB060---14
CNRV*3017A** 1.01 0.93 58MVB060---14
CSRH*2412A** 1.01 0.95 58MVB060---14
CSRH*3012A** 1.01 0.93 58MVB060---14
CNRH*2417A** 1.01 0.95 58MVB080---14
CNRH*3017A** 1.01 0.93 58MVB080---14
CSRH*2412A** 1.01 0.95 58MVB080---14
CSRH*3012A** 1.01 0.93 58MVB080---14
CNRH*2417A** 1.01 0.95 58MVB080---20
CNRH*3017A** 1.01 0.93 58MVB080---20
CSRH*2412A** 1.01 0.95 58MVB080---20
CSRH*3012A** 1.01 0.93 58MVB080---20
CNRH*2417A** 1.01 0.95 58MVB100---20
CNRH*3017A** 1.01 0.93 58MVB100---20
CSRH*2412A** 1.01 0.95 58MVB100---20
CSRH*3012A** 1.01 0.93 58MVB100---20
CNRH*2417A** 1.00 0.94 58MVB120---20
CNRH*3017A** 1.01 0.93 58MVB120---20
CSRH*2412A** 1.01 0.95 58MVB120---20
CSRH*3012A** 1.01 0.93 58MVB120---20
See notes on pg. 24
25HBR3

Carrier 25HBR3 Specifications

Electrical Requirements

nominal unit electrical characteristics (single phase)	v, single phase, 60 hz
nominal unit electrical characteristics (three phase)	v, three phase, 60 hz
control circuit voltage	24v

Fan Specifications

condenser fan type	direct-drive propeller type
condenser fan motor type	totally enclosed, 1-phase type
fan blade balance	statically and dynamically balanced
