HEAT PUMP HEATING PERFORMANCE -- CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
--- 3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
25HBR324A Outdoor Section With FA4CNC024 Indoor Section
65
700 9.96 9.16 1.51 12.42 11.42 1.58 15.20 13.86 1.66 18.29 16.24 1.75 21.61 19.66 1.85 24.08 24.08 1.94 26.42 26.42 2.02 26.97 26.97 2.04
800 10.14 9.33 1.53 12.62 11.60 1.59 15.43 14.07 1.66 18.54 16.47 1.75 21.54 19.60 1.83 23.60 23.60 1.90 24.52 24.52 1.93 23.37 23.37 1.88
900 10.31 9.48 1.56 12.80 11.77 1.61 15.63 14.25 1.67 18.77 16.67 1.76 21.32 19.40 1.82 23.08 23.08 1.88 22.88 22.88 1.87 22.24 22.24 1.85
70
700 9.70 8.92 1.58 12.19 11.20 1.65 14.92 13.61 1.73 18.01 16.00 1.83 21.41 19.49 1.96 24.16 24.16 2.04 26.65 26.65 2.13 28.10 28.10 2.19
800 9.88 9.09 1.60 12.38 11.38 1.67 15.15 13.82 1.74 18.26 16.22 1.83 21.54 19.60 1.92 23.80 23.80 2.00 25.64 25.64 2.06 25.56 25.56 2.05
900 10.05 9.25 1.62 12.56 11.54 1.68 15.36 14.00 1.75 18.48 16.42 1.84 21.47 19.53 1.92 23.41 23.41 1.98 24.03 24.03 2.00 23.70 23.70 1.98
75
700 9.40 8.65 1.64 11.93 10.96 1.73 14.65 13.35 1.81 17.71 15.73 1.92 21.10 19.20 2.04 24.24 24.24 2.15 26.78 26.78 2.25 29.06 29.06 2.34
800 9.59 8.82 1.66 12.13 11.15 1.74 14.88 13.56 1.82 17.96 15.95 1.91 21.36 19.43 2.02 23.92 23.92 2.10 26.17 26.17 2.19 26.68 26.68 2.20
900 9.76 8.98 1.69 12.31 11.31 1.76 15.08 13.75 1.83 18.18 16.15 1.92 21.48 19.54 2.01 23.62 23.62 2.08 25.00 25.00 2.13 24.91 24.91 2.12
Heating Indoor Model Capacity Power Furnace Model
*FA4CN(F,C)024 1.00 1.00
FA4CN(F,C)030 0.95 0.97
FC4DNF024 0.98 0.93
FC4DNF030 0.93 0.90
FF1ENE030 0.99 0.99
FK4DNF001 0.95 0.92
FK4DNF002 0.95 0.88
FK4DNF003 0.87 0.86
CAR**2414A** 1.00 0.99
CAR**2417A** 1.00 0.99
CAR**3014A** 0.87 0.93
CAR**3017A** 0.87 0.93
CNRF*2418A** 1.00 0.96
CNRH*2417A** 1.00 0.96
CNRH*3017A** 0.87 0.93
CNRV*2414A** 1.00 0.96
CNRV*2417A** 1.00 0.96
CNRV*3014A** 0.87 0.93
CNRV*3017A** 0.87 0.93
CSRH*2412A** 0.97 0.96
CSRH*3012A** 0.85 0.92
CAR**2414A** 1.00 0.95 58CV(A,X)070---12
CAR**3014A** 0.92 0.91 58CV(A,X)070---12
CNRH*2417A** 0.99 0.92 58CV(A,X)070---12
CNRH*3017A** 0.87 0.85 58CV(A,X)070---12
CNRV*2414A** 1.00 0.92 58CV(A,X)070---12
CNRV*3014A** 0.87 0.85 58CV(A,X)070---12
CSRH*2412A** 0.97 0.91 58CV(A,X)070 ---12
CSRH*3012A** 0.85 0.84 58CV(A,X)070 ---12
CAR**2417A** 0.99 0.93 58CV(A,X)090---16
CAR**3017A** 0.87 0.85 58CV(A,X)090---16
CNRH*2417A** 0.99 0.91 58CV(A,X)090---16
CNRH*3017A** 0.87 0.84 58CV(A,X)090---16
CNRV*2417A** 0.99 0.91 58CV(A,X)090---16
CNRV*3017A** 0.87 0.84 58CV(A,X)090---16
CSRH*2412A** 0.97 0.90 58CV(A,X)090 ---16
CSRH*3012A** 0.85 0.83 58CV(A,X)090 ---16
CNRH*2417A** 0.99 0.91 58CV(A,X)110---20
CNRH*3017A** 0.87 0.84 58CV(A,X)110---20
CSRH*2412A** 0.97 0.91 58CV(A,X)110 ---20
CSRH*3012A** 0.85 0.84 58CV(A,X)110 ---20
CNRH*2417A** 0.99 0.91 58CV(A,X)135---22
CNRH*3017A** 0.87 0.84 58CV(A,X)135---22
CSRH*2412A** 0.97 0.91 58CV(A,X)135 ---22
CSRH*3012A** 0.85 0.83 58CV(A,X)135 ---22
CNRH*2417A** 0.99 0.91 58CV(A,X)155---22
CNRH*3017A** 0.87 0.84 58CV(A,X)155---22
CSRH*2412A** 0.97 0.91 58CV(A,X)155 ---22
CSRH*3012A** 0.85 0.83 58CV(A,X)155 ---22
Heating Indoor Model Capacity Power Furnace Model
CNRH*2417A** 0.99 0.91 58MVB040---14
CNRH*3017A** 0.87 0.85 58MVB040---14
CSRH*2412A** 0.97 0.91 58MVB040---14
CSRH*3012A** 0.85 0.84 58MVB040---14
CAR**2417A** 0.99 0.93 58MVB060---14
CAR**3017A** 0.87 0.85 58MVB060---14
CNRH*2417A** 0.99 0.91 58MVB060---14
CNRH*3017A** 0.87 0.85 58MVB060---14
CNRV*2417A** 0.99 0.91 58MVB060---14
CNRV*3017A** 0.87 0.85 58MVB060---14
CSRH*2412A** 0.97 0.91 58MVB060---14
CSRH*3012A** 0.85 0.83 58MVB060---14
CNRH*2417A** 0.99 0.91 58MVB080---14
CNRH*3017A** 0.87 0.85 58MVB080---14
CSRH*2412A** 0.97 0.91 58MVB080---14
CSRH*3012A** 0.85 0.84 58MVB080---14
CNRH*2417A** 0.99 0.91 58MVB080---20
CNRH*3017A** 0.87 0.85 58MVB080---20
CSRH*2412A** 0.97 0.91 58MVB080---20
CSRH*3012A** 0.85 0.84 58MVB080---20
CNRH*2417A** 0.99 0.91 58MVB100---20
CNRH*3017A** 0.87 0.84 58MVB100---20
CSRH*2412A** 0.97 0.91 58MVB100---20
CSRH*3012A** 0.85 0.84 58MVB100---20
CNRH*2417A** 0.99 0.92 58MVB120---20
CNRH*3017A** 0.87 0.85 58MVB120---20
CSRH*2412A** 0.97 0.91 58MVB120---20
CSRH*3012A** 0.85 0.84 58MVB120---20
See notes on pg. 31
