6
Physical data
Electrical data
30GH/GZ 040 045 050 060 085 095 100 120 130 145 150 160 170 190 220 245
Power wiring
Nominal power supply V-ph-Hz 400-3-50
Voltage range V 360-440
Auxiliary circuit (heaters) V-ph-Hz 230-1-50
Power input W 570 570 570 570 980 980 1160 1160 1460 1460 1460 1460 1640 1820 2000 2000
Max. unit power input (comp. + fans)**
30GH kW 45 59 70 95 117 142 162 189 209 209 237 237 257 304 349 379
30GZ kW 41 55 64 87 110 134 152 174 192 202 228 225 241 282 328 358
Max. unit power input with separate supply (possibible on 30G 170-245)
30GH circuit A kW - -----------142175175190
30GH circuit B kW - -----------115129175190
30GZ circuit A kW - -----------141165164179
30GZ circuit B kW - -----------100117164179
Fan power supply V-ph-Hz 400-3-50
Fan power input kW 2.3 2.3 4.6 4.6 7 7 7 9 9 9 12 12 12 14 14 19
Max. starting current (comp. + fans)
30GH/GZ standard unit A 144 186 219 296 476 518 553 601 636 636 684 684 719 802 879 934
30GH/GZ with part-winding start A std std std std 338 380 415 463 498 498 546 546 581 664 741 796
30GH/GZ with separate power supply circuit A** A - -----------517574574601
30GH/GZ with separate power supply circuit B** A - -----------469497574601
Max. unit current drawn (comp. + fans)*
30GH A 78 102 120 166 204 250 280 333 364 364 416 416 447 530 608 666
30GZ A 72 97 113 153 194 236 268 306 338 356 401 396 424 496 577 630
30GH with separate power supply circuit A** A - -----------250304304333
30GH with separate power supply circuit B** A - -----------197229304333
30GZ with separate power supply circuit A** A - -----------248290289315
30GZ with separate power supply circuit B** A - -----------176206289315
* Compressor and fan, at maximum unit operating values
** Unit sizes 30GZ 170-245 have a separate power supply per circuit. All currents are given at nominal voltage
30GH/GZ 040 045 050 060 085 095 100 120 130 145 150 160 170 190 220 245
Net nominal cooling capacity*
30GH (R-22) kW 107 124 156 190 255 300 344 396 442 457 498 516 562 631 729 808
30GZ (R-407C) kW 102 118 150 181 244 287 329 379 417 437 476 499 538 603 697 773
Operating weight kg 1380 1445 1710 1780 3012 3067 3439 3884 4330 4452 5010 5172 5592 6442 6742 7992
Refrigerant charge R-22
Circuit A kg 15 15 17.2 19.5 33.2 34.2 29.4 37 48.4 46.5 53.1 59.8 59.8 60 60 67.4
Circuit B kg 15 15 17.2 19.5 19 23.7 29.4 37 32.3 35.1 38.9 47.4 49.3 57 60 67.4
Refrigerant charge R-407C
Circuit A kg 16.5 16.5 19 21.5 24 34 28 36 47 46 53 59 59 59 59 66
Circuit B kg 16.5 16.5 19 21.5 15 24 28 36 32 35 38.5 46 48 56 59 66
Compressors Semihermetic, 4 or 6 cylinders 24.2 r/s (1450 rpm)
Circuit A 11112 2 2 2 3 3 3 3 3 4 4 4
Circuit B 11111 1 2 2 2 2 2 2 3 3 4 4
Control type PRO-DIALOG control
No. of capacity stages 44446 6 4 4 5 5 5 5 6 7 8 8
Minimum capacity % 25 33 33 33 20 22 22 25 17 17 20 20 14 12 10 12.5
Evaporator Direct-expansion, multi-tube shell, two circuits
Net water volume l 55 55 63 63 92 92 154 154 199 242 199 242 242 242 242 242
Water connections Flat flanges PN 16, in accordance with NFE 29 203
Inlet/outlet DN80 DN80 DN80 DN80 DN100 DN100 DN125 DN125 DN150 DN150 DN150 DN150 DN150 DN150 DN150 DN150
Drain (NPT) in 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
Max. water side operating pressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Condenser Copper tubes and aluminium fins
Fans Shrouded axial FLYING-BIRD fan
Quanitity 22446 6 6 8 8 8 101010121216
Total air flow l/s 9944 9944 19890 19890 29830 29830 29830 39780 39780 39780 49720 49720 49720 59670 59670 79560
Speed r/s 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5 12.5
* Standard Eurovent conditions: Evaporator entering/leaving water temperature 12°C and 7°C. Condenser entering air temperature 35°C.
Net cooling capacity = gross cooling capacity minus the water pump heat against the internal evaporator pressure drop.
Electrical data notes (cont.)
• 30GZ units have a single power connection point (except 30GZ 170-245 which have two connection
points).
• A separate power source (230 V, 1 ph, 50 Hz) that does not exceed the main switch capacity is
required to power the compressor crankcase heater circuit. This source must be supplied from a
transformer. It must not be supplied from a phase + neutral supply (for ground + neutral systems).
• The control box includes the following standard features:
- Starter and motor protection devices for each compressor and the fan(s)
- Control devices
• Field connections:
All connections to the system and the electrical installations must be in full accordance with all
applicable local codes.
• The Carrier 30GZ chillers are designed and built to ensure conformance with these codes. The
recommendations of European standard EN 60 204-1 (machine safety - electrical machine
components - part 1: general regulations) are specifically taken into account, when designing the
electrical equipment.
NOTES:
• Generally the recommendations of IEC 364 are accepted as compliance with the requirements of the
installation directives. Conformance with EN 60 204 is the best means of ensuring compliance with
the Machines Directive § 1.5.1.
• Annex B of EN 60204-1 describes the electrical characteristics used for the operation of the
machines.
1. The operating environment for the 30GZ chillers is specified below:
• Environment* - Environment as classified in EN 60 721:
- outdoor installation*
- ambient temperature range: -18°C to +46°C, class 4K4H*
- altitude: ≤ 2000 m
- presence of hard solids, class 4S2 (no significant dust present)
- presence of corrosive and polluting substances, class 4C2 (negligible)
- vibration and shock, class 4M2
• Competence of personnel, class BA4* (trained personnel - IEC 364)
2. Power supply frequency variation: ± 2 Hz.
3. The neutral (N) line must not be connected directly to the unit (if necessary use a transformer).
4. Overcurrent protection of the power supply conductors is not provided with the unit.
5. The optional factory-installed circuit breaker is of type “a” (EN 60 204-1 § 5.3.2).
NOTE: If particular aspects of an actual installation do not conform to the conditions described above, or
if there are other conditions which should be considered, always contact your local Carrier representative.
* The required protection level for this class is IP43BW (according to reference document IEC 529). All
30GZ units are protected to IP44CW and fulfill this protection condition.
