Table 5A — Compressor Electrical Data, 30HXC Units (cont)
UNIT SIZE
30HXC
NAMEPLATE
V-Hz
(3 Phase)
COMPRESSOR NUMBERS
A1 B1
RLA LRA RLA LRA
186
208/230-60 * * * *
460-60 103.1 685 103.1 685
575-60 82.4 548 82.4 548
380-60 124.8 757 124.8 757
230-50 * * * *
346-50 * * * *
380/415-50 128.6 856 128.6 856
186-WD
208/230-60 228.8 433 228.8 433
460-60 103.1 216 103.1 216
575-60 82.4 173 82.4 173
380-60 124.8 239 124.8 239
230-50 212.5 432 212.5 432
346-50 141.0 297 141.0 297
380/415-50 128.6 270 128.6 270
LEGEND
LRA — Locked Rotor Amps
RLA — Rated Load Amps
WD — Wye-Delta Start
*Units are shipped with wye-delta start as standard. Across-the-line start is not available.
21
