Table 5B — Compressor Electrical Data, 30HXA Units (cont)
UNIT SIZE
30HXA
NAMEPLATE
V-Hz
(3 Phase)
COMPRESSOR NUMBERS
A1 B1
RLA LRA RLA LRA
126
208/230-60 * * * *
460-60 115.4 820 94.8 685
575-60 92.2 656 75.7 548
380-60 139.7 906 114.7 757
230-50 * * * *
346-50 * * * *
380/415-50 145.4 960 119.9 856
126-WD
208/230-60 255.5 518 209.8 447
460-60 115.4 259 94.8 216
575-60 92.2 207 75.7 173
380-60 139.7 286 114.7 239
230-50 240.2 485 198.2 432
346-50 159.4 334 131.4 297
380/415-50 145.4 303 119.9 270
136
208/230-60 * * * *
460-60 140.7 920 94.8 685
575-60 112.4 736 75.7 548
380-60 170.2 1017 114.7 757
230-50 * * * *
346-50 * * * *
380/415-50 178.8 1226 119.9 856
136-WD
208/230-60 311.4 581 209.8 433
460-60 140.7 291 94.8 216
575-60 112.4 233 75.7 173
380-60 170.2 321 114.7 239
230-50 295.3 619 198.2 432
346-50 195.9 426 131.4 297
380/415-50 178.8 387 119.9 276
146
208/230-60 * * * *
460-60 140.7 920 115.4 820
575-60 112.4 736 92.2 656
380-60 170.2 1017 139.7 906
230-50 * * * *
346-50 * * * *
380/415-50 178.8 1226 145.4 960
146-WD
208/230-60 311.4 581 255.5 518
460-60 140.7 291 115.4 259
575-60 112.4 233 92.2 207
380-60 170.2 321 139.7 286
230-50 295.3 619 240.2 485
346-50 195.9 426 159.4 334
380/415-50 178.8 387 145.4 303
161
208/230-60 * * * *
460-60 157.9 1175 106.6 790
575-60 126.2 940 85.1 630
380-60 191.2 1299 129.0 870
230-50 * * * *
346-50 * * * *
380/415-50 201.2 1265 133.4 1045
161-WD
208/230-60 349.6 743 235.9 527
460-60 157.9 371 106.6 263
575-60 126.2 297 85.1 211
380-60 191.2 410 129.0 290
230-50 332.3 638 220.3 607
346-50 220.5 439 146.2 402
380/415-50 201.2 400 133.4 348
171
208/230-60 * * * *
460-60 129.6 920 157.9 1175
575-60 103.6 736 126.2 940
380-60 156.9 1017 191.2 1299
230-50 * * * *
346-50 * * * *
380/415-50 161.7 1226 201.2 1265
171-WD
208/230-60 286.9 581 349.6 743
460-60 129.6 291 157.9 371
575-60 103.6 233 126.2 297
380-60 156.9 321 191.2 410
230-50 267.2 619 332.3 638
346-50 177.3 426 220.5 439
380/415-50 161.7 387 201.2 400
LEGEND
LRA — Locked Rotor Amps
RLA — Rated Load Amps
WD — Wye-Delta Start
*Units are shipped with wye-delta start as standard. Across-the-line start is not available.
