112 Specifications subject to change without notice. SG-38MARB-01
Procedure Illustration
3) Remove the hex nuts and washers securing
the compressor, located on the bottom
plate.
4) Heat up the brazed parts and then remove
the discharge pipe and the suction
pipe.
5) Lift the compressor from the base pan
assembly with pliers.
Discharge Pipe
Suction Pipe
