8 Specifications subject to change without notice. OG-40MBFQ-04
FAN Mode
Fig. 11 — FAN Mode
1. Press MODE to select the FAN mode.
2. Press FAN to select the fan speed in the range of AU-100%.
3. Press ON/OFF to start the unit.
REMOTE CONTROL FUNCTIONS
Pressing ON/OFF
When the air conditioner is not in operation, the remote control
displays the last set point and mode.
• Press ON/OFF to start the unit.
- The unit starts in the last operating mode and set point. The
ON/OFF indicator appears.
• Press ON/OFF to stop the unit.
- All the indicator lights on the unit go out, and the remote
control displays the set point and mode.
NOTE: If ON/OFF is pressed too soon after a stop, the
compressor will not start for 3 to 4 minutes due to the inherent
protection against frequent compressor cycling. The unit only
emits an audible beep when the signals are received correctly.
Selecting an Operating Mode
Use OPERATING MODE to select one of the available modes.
Fig. 12 — Operating Modes
Setting the Room Temperature Set Point
Press TEMP or TEMP to raise or lower the temperature.
The unit confirms the signal receipt with a beep and the value
of the set temperature appears on the display and changes
accordingly. The temperature can be set between 62F (17C) and
86F (30C) in increments of 1°F or 1°C.
NOTE: In the COOLING mode, if the temperature selected is higher
than the room temperature, the unit will not start. The same applies for
the HEATING mode if the selected temperature is lower than the
room temperature.
Selecting the Fan Speed
Fig. 13 — Fan Speeds
Press FAN to select the fan speed.
NOTE: When the unit is on, the fan runs continuously in cooling or
heating. When in heating, there might be situations where the fan will
slow down or shut off to prevent cold blow.
EQUIPMENT DAMAGE HAZARD
Failure to follow this caution may result in equipment damage.
Handle the controller with care and avoid getting it wet.
CAUTION
AUTO
LOW
MED
HIGH
