Table 11 – Unit Wire/MOCP Sizing Data
UNIT
N O M . V --- P H --- H Z
IFM
TYPE
ELECTRIC HEATER
CRHEATER***A00
Nom
(kW)
FLA MCA MOCP
DISC. SIZE
FLA LRA
50TC*A07
4 0 0 --- 3 --- 5 0
STD
--- --- 15.4 25 15 75
CRHEATER106A00
6.0 6.0 15.4 25 15 75
CRHEATER108A00
11.5 11.5 17.6 25 16 75
CRHEATER109A00
14.0 14.0 20.8 25 19 75
CRHEATER108A00,108A00
23.1 23.1 32.1 35 30 75
CRHEATER108A00,109A00
25.6 25.6 35.3 40 32 75
HIGH
--- --- 16.2 25 16 94
CRHEATER106A00
6.0 6.0 16.2 25 16 94
CRHEATER108A00
11.5 11.5 18.6 25 17 94
CRHEATER109A00
14.0 14.0 21.8 25 20 94
CRHEATER108A00,108A00
23.1 23.1 33.1 35 30 94
CRHEATER108A00,109A00
25.6 25.6 36.3 40 33 94
50TC*D08
4 0 0 --- 3 --- 5 0
STD
--- --- 17.5 20 18 99
CRHEATER116A00
13.9 13.9 20.6 25 19 99
CRHEATER113A00
16.5 16.5 23.9 25 22 99
CRHEATER114A00
27.9 27.9 38.1 40 35 99
CRHEATER115A00
33.1 33.1 44.6 45 41 99
CRHEATER114A00,116A00
41.8 41.8 55.5 60 51 99
MED
--- --- 18.3 20 19 118
CRHEATER116A00
13.9 13.9 21.6 25 20 118
CRHEATER113A00
16.5 16.5 24.9 25 23 118
CRHEATER114A00
27.9 27.9 39.1 40 36 118
CRHEATER115A00
33.1 33.1 45.6 50 42 118
CRHEATER114A00,116A00
41.8 41.8 56.5 60 52 118
HIGH
--- --- 22.7 30 24 171
CRHEATER116A00
13.9 13.9 26.6 30 24 171
CRHEATER113A00
16.5 16.5 29.9 30 27 171
CRHEATER114A00
27.9 27.9 44.1 45 41 171
CRHEATER115A00
33.1 33.1 50.6 60 47 171
CRHEATER114A00,116A00
41.8 41.8 61.5 70 57 171
NOTE: See page 38 for table legend and notes.
