30RA/30RH Puron
Water chillers, air-cooled with integrated hydronic section
GB - 1
ENGLISH
Table I
For operation and maintenance instructions of this unit as well as installation
instructions of the indoor unit, refer to the relevant manuals.
Contents
Pagina
Dimensions and weight ................................................................................................................. 2
Technical data................................................................................................................................2
Minimum clearances...................................................................................................................... 3
Electrical data ................................................................................................................................3
Data ............................................................................................................................................... 4
General information ....................................................................................................................... 5
Warnings: avoid ............................................................................................................................. 6
Water connections ......................................................................................................................... 7
Connections and water circuits ..................................................................................................... 8/9
Electrical connections.................................................................................................................... 10/12
Water-refrigerant heat exchanger ................................................................................................. 12/13
Check the refrigerant charge ......................................................................................................... 14
Unit maintenance........................................................................................................................... 14
Control and safety devices ............................................................................................................ 14
Diagnostics .................................................................................................................................... 15
Troubleshooting and guide for the owner ...................................................................................... 16
Accessories ................................................................................................................................... 16
ATTENTION INSTALLERS AND SERVICE TECHNICIANS!
AIR CONDITIONER WITH R-410A REFRIGERANT
• R-410A refrigerant operates at 50%-70% higher pressures than R-22. Be sure that servicing
equipment and replacement components are designed to operate with R-410A.
• R-410A refrigerant cylinders are pink in colour.
• R-410A refrigerant cylinders have a dip tube which allows liquid to flow out of the cylinder in upright
position.
• The R-410A units must be charged with refrigerant in a liquid state. Use a commercial type metering
device in the manifold hose in order to vaporize the liquid refrigerant before it enters in the unit.
• R-410A, as other HFCs, is only compatible with the following oils selected by the compressor
manufacturer.
• The vacuum pump is not sufficient to remove moisture from the oil.
• POE oils absorb moisture rapidly. Do not expose oil to atmosphere.
• Never open unit to atmosphere while it is under a vacuum.
• When unit must be opened for service, break vacuum with dry nitrogen and replace filter dryer.
• Do not vent R-410A into the atmosphere.
Cooling only models Heat pump models Power supply
30RA005---7 30RH005---7 230 V ~ 50 Hz
30RA007---7 30RH007---7 230 V ~ 50 Hz
30RA007---9 30RH007---9 400 V 3N~ 50 Hz
30RA009---9 30RH009---9 400 V 3N~ 50 Hz
30RA011---7 30RH011---7 230 V ~ 50 Hz
30RA011---9 30RH011---9 400 V 3N~ 50 Hz
30RA013---9 30RH013---9 400 V 3N~ 50 Hz
Unit size Oil type
Quantity Drier already installed on
l liquid line of the unit
005 - 007 POE 1.12 YES
009 - 011 POE 1.25 YES
013 POE 1.95 YES
