5. PARTS LIST: MODULE QW-2960

Note: 1. Prices and specifications are subject to change without prior notice.

2. Spare parts are classified as follows according to their importance in after-sales service.

A Rank ---------------------------------------- Very Important

B Rank ---------------------------------------- Important

C Rank ---------------------------------------

Less important

3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.

Batteries in Blister pack will be supplied from our Sales Department.

4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".

Item Code No. Parts Name Specification Applicable Q R

76408734 MODULE/WITHOUT MOVEMENT QW-2960AT-01TK BGX-260-1/5 1 A

76408735 MODULE/WITHOUT MOVEMENT QW-2960AT-02TK BGX-260-2A/2B 1 A

76408736 MODULE/WITHOUT MOVEMENT QW-2960AT-03TK BGX-260-4 1 A

1 10065657 BATTERY/STORAGE CTL1616 QW-2960AT Common 1 B

2 10010950 CAPACITOR/TRIMMER CTZ2E-30C-W2-P QW-2960AT Common 1 B

3 72311913 CONTACT/BATTERY(-) 1828 Q359948B-2 QW-2960AT Common 1 C

4 72110064 CUSHION 6 Q4914A-1 QW-2960AT Common 1 C

5a 10106538 EL YEL-2611-A-00 QW-2960AT-01TK 1 A

5b 10189346 EL YEL-2611-A-20 QW-2960AT-02TK 1 A

5c 10106539 EL YEL-2611-A-60 QW-2960AT-03TK 1 A

6 10083364 HOLDER/BATTERY 2154 Q254197A-2 QW-2960AT Common 1 C

7 10106531 INTERCONNECTOR/ 2611 Q470668-1 QW-2960AT Common 2 C

8 10065664 LABEL/ 2368 Q468543A-1 QW-2960AT Common 1 C

9 10189345 LCD K2960-01THP QW-2960AT Common 1 A

10 71106323 OSCILLATOR/CRYSTAL DT-26S11 QW-2960AT Common 1 B

11 76408729 PCB ASS'Y Q256046*4TK QW-2960AT Common 1 A

12 71055275 SENSOR/TILT TS-2418-P QW-2960AT Common 1 B

13 10099862 SHEET/INSULATION 2620-1 Q470524-1 QW-2960AT Common 1 C

14 10106530 SPACER/ 2611-2 Q470667-1 QW-2960AT Common 1 C

15 72019249 SPRING/COIL 675-3 Q413389A-1 QW-2960AT Common 1 B

16 10106532 SPRING/COIL 2611-1 Q470669A-1 QW-2960AT Common 2 B

17 10106533 SPRING/COIL 2611-2 Q470687-1 QW-2960AT Common 2 B

For the prices and minimum order/suppl

quantities of the above parts, refer to the Parts Price List P.P.L.-620.

Notes: Q - Used quantity

R - Rank

— 12 —
