Casio CTK-330 User Manual

Item Code No. Parts Name Specification Q R
Main PCB
1 6925 4480 Main PCB ass'y M441-MA1,2M M140451*1 1 B
LSI101 2012 3948 LSI, CPU MSM6755B-08 1 A
IC101 2114 2891 IC, Amp. LA4598 1 A
IC102 2105 5922 IC RE5VL40AA-TZ 1 A
Q101 2250 0168 Transistor 2SA854SR-TP-T 1 A
Q102, Q105 - Q110, 2220 1387 Transistor 2SC1740SQ-TP-T 8 A
Q112
Q103, Q104 2253 0448 Transistor 2SD1858Q,R-TV6-T 2 A
Q111 2200 2449 Transistor 2SA933SQ-TP-T 1 A
D101 2390 0371 Diode DSK10B-BT-T 1 B
D102 2390 1323 Diode RB100A-T32-T 1 B
D103, D105, 2390 1344 Diode 1SS133T-77-T 23 C
D107 - D127
D106 2360 2002 Diode, Zener MTZJ5.6B-T77-T
1
B
D128 2390 2828 Diode RB441Q-40T-77
1
B
D133 2360 1715 Diode, Zener MTZJ3.9B-T77-T
1
B
LED101 2370 1309 LED LB-603VF1 1 B
X101 2590 1526 Ceramic oscillator EFO-EN2005C4 1 B
J101 3501 7049 Jack, Power HEC2305-01-330
1
B
J102 3612 0665 Jack, Phone YKB21-5006 1 C
Keyboard PCB
2 6925 4490 Keyboard PCB ass'y M140449*1 1 C
D701 - D749 2301 0101 Diode 1S2473T-77-T 49 B
Mechanical Parts
3 6922 2720 White key set, LT-CB M312118*1 3
A
4 6922 2730 White key set, LT-CS
M312118*2 1
A
5 6922 2740 Black key set, LT-10P M111726-1 2
A
6 6922 4000 Key contact rubber, 31-contact M111765-1
1
A
7 6923 2390 Key contact rubber, 18-contact M240025-1
1
A
8 6925 4500 Battery cover M340528*1
1B
9 6925 4510 Rubber button M240463-1
1
B
10 6925 4520 Rubber button M240464-1
1
B
11 6909 5890 Slide contact CSB-12D
1
B
12 6921 5030 Slide knob M311859-1
1
B
13 6925 4530 Display plate M340511-1 1
C
14 3831 0770 Speaker S10JA13A
2
B
Accessory
6916 7880 Music stand M310827-1
1B
Notes: Q – Used quantity
R – Rank
— 13 —
