— 3 —
BLOCK DIAGRAM
KO0~KO9
KI0~KI7
Keyboard
Switches
Oscillator
Q301, X301
VDD +5 V
Power supply circuit
Q101, Q102, D102
VC +9 V
Amplifier
A4598
IC101
Speaker
Filter
Q201
CPU
MSM6387-13
LSI201
Main Volume
AVDD +4.8 V
