– 21 –
15-3. Remove the hooks and then Key PCBs (M802-KYA1/KYA2).
M802-KYA1
M802-KYA2
15-4. Remove the rubber keys.
1 32 4 5
Caution while assembling:
There are two types of rubber keys and they are different in length.
The longest rubber key (
5
) must be installed at the right end.
How to install the rubber keys.
