Casio CTK-800 User Manual

— 18 —
N Item Parts Code Parts Name Specification QTY
Price
Code
R Remarks
Ke
y
board PCBs
5 10053891 PCB ASSY/KY1M M140687*9 1 C
D501 - D564
23010101 DIODE 1S2473T-77-T 64 X
6 10053893 PCB ASSY/KY2M M140688*9 1 C
D565 - D622
23010101 DIODE 1S2473T-77-T 58 X
Ke
y
board Unit
7 69222720 KEY SET/LT WHITE M312118*1 4 C
8 69222730 KEY SET/LT WHITE M312118*2 1 C
9 69068481 KEY SET/LT BLACK 10P M140369A-3 2 C
10 69068591 KEY SET/LT BLACK 5P M140369A-4 1 C
11 69222762 RUBBER/CONTACT M211704B-1 4 B
12 69222772 RUBBER/CONTACT M211705B-1 1 B
Case Unit
N 13 10199878 REFLECTOR RJM505455-001V01 1 C
N 14 10203310 COVER ASSY/BATTERY TK-M341235*003 1 C
15 69273030 PACKING M440775-1 2 C
16 10116376 LED SLR343BBT3F 2 C
N 17 10199865 PLATE/DISPLAY RJM505452-001V01 1 C
18 10199714 KNOB/SLIDE RJM503803-002V01 2 C
N 19 10197646 KNOB/ROTARY RJM502503-010V01 1 C
N 21 10199866 RUBBER KEY/A RJM505441-001V01 1 C
N 22 10199867 RUBBER KEY/B RJM505442-001V01 1 C
N 23 10199868 RUBBER KEY/C RJM505443-001V01 1 C
N 24 10199869 RUBBER KEY/D RJM505444-001V01 1 C
N 25 10199870 RUBBER KEY/E RJM505445-001V01 1 C
N 26 10199871 RUBBER KEY/F RJM505446-001V01 1 C
N 27 10199872 RUBBER KEY/G RJM505447-001V01 1 C
N 28 10199873 RUBBER KEY/H RJM505448-001V01 1 C
N 29 10199874 RUBBER KEY/J RJM505449-001V01 1 C
N 30 10199875 RUBBER KEY/K RJM505450-001V01 1 C
31 69270510 SWITCH/SLIDE KNOB CSB-08D 1 C
N 32 10199877 LCD TR4363N 1 C
N 33 10199879 PLATE/BL RJM505456-001V01 1 C
N 34 10199881 TOP PIECE RJM505457-001V01 1 C
N 35 10199880 FILM RJM505454-001V01 1 C
N 36 10199876 CONNECTOR RJM505453-001V01 2 C
38 69224480 DUMPER/KEY M412324-1 1 C
39 38311096 SPEAKER S12J89A 2 C
40 69032150 SPRING/BATTERY
(
+
)
M41330-1 1 C
41 69026141 SPRING/BATTERY
(
-
)
M41226A-1 1 C
Accessories
- 10107083 STAND/MUSIC M141071-5 1 C
- 69321739 BATTERY R20PNR/2SK 3 C
N - 10199852 LABEL/RATING M341007-053V01 1 X
- 10197572 CD ROM USB12CDROMWL1B 1 C
Refurbish
N R-1 10203308 CASE ASSY/UPPER TK-RJM505748*001 1 C
R-2 10086645 CASE ASSY/MIDDLE M141274*008 1 C
R-3 69069252 PLATE/BOTTOM M240573-2 1 C
Notes : Q- Quantity per unit
R- Rank
