8. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Quantity M N.R.Yen R
A B C Unit Price
PCB L224-1 ASS'Y
N LSI 2012 1295 LSI MN158418YCY 1
11 1
B
IC1, 2 2114 2436 Mos IC BA12003 2
22 5
B
Q1 2251 0525 Transistor 2SB1329-Q,R 1
1110
B
Q3, 4 2252 0896 Transistor 2SC1740S-R,S 2
2220
B
Q5 2250 0672 Transistor 2SA933S-R,S 1
1120
B
Q6 2251 0581 Transistor 2SB1374-Q,R 1
1110
B
Q7, 8 2259 1449 Digital transistor DTD114ES 2
2220
B
D1~5 2390 0378 Diode 1SR139-100T-32-T 5
5520
C
D6~8 2360 1946 Zener diode MTZJ5.6CT-77-T 3
3320
C
D9~11 2301 0054 Diode 1S2472-T-77-T 3
3320
C
D13, 14 2301 0101 Diode 1S2473-T-77-T 2 2 2 20 C
The following elecrical parts will be not supplied from CASIO.
C1, 8 Semiconductive capacitor 0.1uF, 50V, +20/-80% 2
22
C2 Electrolytic capacitor 330uF, 50V 1
11
C4 Ceramic capacitor 1pF, 50V, ±10% 1
11
C5 Electrolytic capacitor 10uF, 16V 1
11
C6 Semiconductive capacitor 0.22uF, 12V, +20/-80% 1
11
C7 Ceramic capacitor 10pF, 50V, ±5% 1
11
C9,10 Ceramic capacitor 0.01uF, 50V, +20/-80% 2 2 2
R1 Carbon film resistor 6.8Kohm, 1/2W, ±5% 111
R2 Carbon film resistor 3.9Kohm, 1/2W, ±5% 111
R5 Carbon film resistor 3.3Kohm, 1/4W, ±5% 111
R6 Carbon film resistor 15Kohm, 1/4W, ±5% 111
R7 Carbon film resistor 1Kohm, 1/4W, ±5% 111
R8 Carbon film resistor 3.6Kohm, 1/4W, ±5% 111
R9 Carbon film resistor 470ohm, 1/4W, ±5% 111
R10 Carbon film resistor 270ohm, 1/4W, ±5% 111
R11 Carbon film resistor 390ohm, 1/4W, ±5% 111
R12 Carbon film resistor 5.1Kohm, 1/4W, ±5% 1
11
R13 Carbon film resistor 20ohm, 1/2W, ±5% 1
11
R14 Carbon film resistor 6.8Kohm, 1/4W, ±2% 1
11
R15 Carbon film resistor 200ohm, 1/4W, ±5% 1
11
R17~19 Metal film resistor 100ohm, 1W, ±5% 3
33
N 1 6055 1760 PCB L224-1 Ass'y P240033A*1HK 1
11 1
B
(This ass'y contains the above parts as its element.)
PCB UNIT
N 1 6055 1760 PCB L224-1 Ass'y P240033A*1HK 1
11 1
B
2 3301 0217 Display tube FG138AW7 1
11 1
A
3 6053 7440 PC joiner B-V298 P310141-4 1
11 5
C
N 4 1014 8290 Digital printer M-80-021 1
11 1
A
N C3 2803 8199 Electrolytic capacitor RE2-25V222M-T50 1
11 5
C
Notes: N – New parts Essential
M – Minimum order/supply quantity Stock recommended
R – Rank Others
Q – Quantity used per unit No stock recommended
R – A :
B :
C :
D :
A : DR-120XA
B : DR-320A
C : DL-220BAGY
— 10 —
