5. PARTS LIST: MODULE QW-1424
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ---------------------------------------- Very Important
B Rank ---------------------------------------- Important
C Rank ---------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name Specification Applicable Q R
7640 3092 MODULE/WITHOUT MOVEMENT QW-1424DF-01TK DW-6100CF-3/8 1 A
1 7001 2963 LCD S974-03TTP QW-1424DF-01TK 1 A
2 7640 5643 PCB ASS'Y Q250766*1TK QW-1424DF-01TK 1 A
3 7103 0458 CAPACITOR/TRIMMER TSF-2L2-120-4.2 QW-1424DF-01TK 1 B
4 7110 1177 OSCILLATOR/CRYSTAL DT-26S04 QW-1424DF-01TK 1 B
5 7225 1768 CONTACT/BATTERY
(
-
)
Q34225D-1 QW-1424DF-01TK 1 C
6 7218 0224 CUSHION/503 Q49959-1 QW-1424DF-01TK 1 C
7 7211 9631 CUSHION/506 Q49364-1 QW-1424DF-01TK 1 C
8 7211 0064 CUSHION/6 Q4914-1 QW-1424DF-01TK 1 C
9 7218 1857 CUSHION/974-1 Q431447-1 QW-1424DF-01TK 2 C
10 7010 4685 INTERCONNECTOR Q465459-1 QW-1424DF-01TK 2 C
11 7104 0097 LAMP/MICRO MLA-7B QW-1424DF-01TK 1 C
12 7212 7649 PLATE/SWITCH 974-1 Q431234-1 QW-1424DF-01TK 2 C
13 7212 7657 PLATE/SWITCH 974-2 Q431235-1 QW-1424DF-01TK 2 C
14 7212 7665 PLATE/TERMINAL Q333242A-1 QW-1424DF-01TK 1 C
15 7215 5056 REFLECTOR/974 FG30-974P QW-1424DF-01TK 1 C
16 7207 8742 SCREW/910 Q426737-1 QW-1424DF-01TK 4 C
17 7042 0155 SCREW/TAPPING Q41054A-1 QW-1424DF-01TK 4 C
18 7201 9679 SPRING/COIL 974-1 Q431453-1 QW-1424DF-01TK 1 B
19 7201 9687 SPRING/COIL 974-2 Q431454-1 QW-1424DF-01TK 1 B
20 7212 7561 SUPPORTER/LCD Q331460A-1 QW-1424DF-01TK 2 C
BATTERY/LITHIUM CR2016C QW-1424DF-01TK 1
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-586.
Notes: Q - Used quantity
R - Rank
— 5 —
